geminox THI 10-50 C User Manual

- 12 -
GAS CONVERSION
- Combustion product evacuation outlet back pres-
sure: 0 mmCE.
- P
o
/ P_OUT = Gas pressure at the gas valve re-
gulator outlet.
- PL = Servo-system air pressure (Fan/gas unit).
- The Po
/ P_OUT and PL values may be more or
less high according to whether back pressure is
greater or smaller.
2.2 - Setting table
Models THI 10-50 THI 10-35 SEP
Burner type X07.36237
Heat output 30/50 °C
60/80 °C
kW
kW
10,7/52,6
9,7/48,7
10,7/36,0
9,7/33,1
Heating Heating D.H.W
Heat input kW 10,0/50,0 10,0/35,0 10,0/50,0
∅ Gas reducer Nat. gas H
Propane
mm
mm
-
6,40
-
-
∅ Air reducer Nat. gas H
Propane
mm
mm
-
31
-
-
Gas flow (15 °C 1013 mbar)
Nat. gas H
Propane
m
3
/h
kg/h
1,06/5,29
0,78/3,88
1,06/3,70
-
1,06/5,29
-
Gas pressure P
o
/ P_OUT (Gas unit to burner)
mbar 0,25/2,4
Air pressure servo-system (PL) Pa 40/630
CO
2
Emission Nat. gas H
Propane
%
%
8,0-8,5/9,0-9,5
10,0-10,5/10,5-11,0
8,0-8,5/9,0-9,5
-
CO Emission Nat. gas H
Propane
ppm
ppm
0/20
0/40
0/20
-
