geminox THI 10-50 C User Manual

- 28 -
PARTS LISTS
Rep.
Reference
Description
1 N40.16810 REDUCED FLUE OUTLET PIPE F75/M80 L360
2 A00.23624 PE CAP N152 BPF 3-1/2
3 Y00.14139 FASTENING HOOK
4 Y00.10807 FIXING SYSTEM FOR FLUE PIPE
5 Y00.13849 BACK STOP PLATE FOR MZ (3355X80,4X1,5)
6 Y00.18233 RIGHT HAND CONSOLE (269,4X25X1,5)
7 V07.31963 WALL FASTENING ; 10-50 MODEL
8 Y90.33470 CHASSIS ; EQUIPPED THI 10-50
9 A00.24109 ORANGE CAP D. 34,7 EZ-16
10 E00.01005 O’ RING DIA DIA 29,32 X 3,6
11 L90.24635 AUTOMATIC AIR VALVE WATTS WITH ISOLATED VALVE
12 U00.19465 HEATING FLOW PIPE GREY THRC
13 E20.03889 SEALING AFM34D 30X21X3
14 W07.32303 OUTSIDE SENSOR .QAC34/101 THRI
15 H30.24159 MESSING CAP 28X52 + 2 O’RING
16 U90.28983 HEATING RETURN UNIT
17 I20.21441 MESSING SEALED CONNECTION "OLIVE" 22/1
18 V00.23999 STOP PLATE FOR HEATING AND DHW
19 V00.21491 PROTECTING RING 1
20 I20.21452 MESSING LOCK NUT 1
21 K50.24473 DRAIN COCK / RETURN UNIT
22 E00.24496 SEALING / O’RING INT. D. 39,45
23 L40.24495 STAINLESS STEEL FILTER / HEATING RETURN
24 L50.35152 PRESSURE SENSOR HUBA TYPE 505.91540
24 V90.35156 REPLACEMENT SET OF IMIT SENSOR BY HUBA SENSOR
25 L90.24178 SAFETY VALVE
26 L20.31471 SENSOR T7335D1024B
27 L30.33738 CIRCULATING PUMP GRUNDFOS UPS15-70/130 AO S3
28 U00.19252 SUMP INLET THRC/S GREY
29 A20.23655 SIPHONIC TRAP WITH PIPE 650 MM
30 W07.31562 CONTROL BOX PROGRAMMED THRI/THI 10-50C (DT)
31 U07.31500 GAS INLET; EQUIPPED; 1/10 - 5/25 MODEL
32 Y90.35965 WHITE COVER THRI S/10-50C
33 T25.31875 FIXING PART; UPPER COVER
34 E20.03890 SEALING AFM34 D 24X17X3
35 H20.32834 FRONTPANEL GREY
36 Y07.32843 COVER + FRONTPANEL
37 V07.32114 RING FOR BOILER COVER L685
38 L20.31470 SENSOR TASSERON NTC SENSOR M5 TSA-TYPE
39 L10.10607 HONEYWELL O’RING 22 X 2,5
40 V90.33616 WIRED SIT GAS VALVE SET
40 V90.37322 GAS VALVE SIEMENS VGU 87
41 I20.31604 GAS REDUCER
42 L10.33774 FLANGE G 3/4" FOR SIT VALVE
43 U07.31563 GAS INLET; COMPLETE BURNER ; 10-50C MODEL
44 U07.31498 90° ELBOW ; D.80 DRILLED
45 L20.31496 SENSOR TASSERON NTC SENSOR D10X20 10K
46 T20.00582 SIGHTGLASS PYREX D.30X5
47 B59.00692 STAINLESS STEEL WASHER 30,4X25,5X0,3
48 T40.01051 INSIDE CIRCLIPS D.30 YELLOW BICHROMATE
49 L00.16673 IGNITION ELECTRODE SHORT 74,5 AV CABLE
50 L00.12950 IONISATION PROBE (SHORT 20)
51 X00.24278 BURNER SET NG/LPG FOR THR 10-50 C
52 X00.32003 BURNER RING; REMOVABLE
53 F00.26573 GLASS BRAID RING D. 12 LG. 1070
