geminox THI 10-50 C User Manual

- 34 -
PARTS LISTS
Rep.
Reference
Designation
1 H20.31449 CONTROL BUTTON
2 Y07.31525 CONTROL PANEL + STICKER
3 W07.31892 INTERFACE; EQUIPPED; AGU2.303A136
4 L20.31476 COMMUNICATION MODULE CLIP-IN LPB (VOIR OPTION W07.30832)
4 L20.31477 MODULE CIRCUIT 2 CLIP-IN (VOIR OPTION W07.30833)
4 L20.31499 SUB-MODULE RELAIS CLIP-IN AGU2.511A109 (VOIR OPTION W07.30515)
5 L20.36214 ELECTRONIC CONTROL UNIT LMU64.010D136 V3.03
6 A90.27098 CABLE GRIP D=6,5 MM BLACK
6 C91.38454 CABLE FASTENING TWIST LOCK
7 Y07.31507 ELECTR. BOX
8 C19.32006 SCREW EARTH CONNECTION
9 C20.12490 TIGHT CAP FOR SWITCH
10 C20.12487 BIPOLAR SWITCH; BLACK/LIGHTNING/GREEN
11 L25.17432 TIMER GRASSLIN 230 V FM - DIGI20
* C09.31469 CABLE WITH RECTIFIER VDU GAS VALVE
* C09.33608 CABLE 0.960.401+CONNECT. GAS VALVE SIT 848 SIGMA
* C09.37989 IONISATION CABLE Ø 2,5 LG 1020 MM
* C09.37989 IONISATION CABLE Ø 2,5 LG 1020 MM
* C90.31497 COVER KEY-TOP 4X4 THISION
* W07.31478 WIRING OF THE CONTROL BOX
* W07.31479 WIRING OF THE CONTROL BOX; 10-50 MODEL
* W07.31492 CONNECTING CABLE LG LMU64/AGU2
* W07.31508 ELECTR. CONTROL BOX + WIRING 2-13 THISION
* W07.31542 ELECTRICAL TERMINAL BOX
* W07.31558 ELECTR. CONTROL PANEL + WIRING 0,9-9 THISION
* W07.31562 CONTROL BOX PROGRAMMED THRI/THI 10-50C (DT)
* W07.32380 CONTROL BOX ; WIRED ; PROGRAMMED THI 5-25 S DT
* W07.32381 CONTROL BOX ; WIRED ; PROGRAMMED THI 2-13 M 75 DT
* W07.32382 CONTROL BOX; WIRED; PROGRAMMED THI 5-25 M75 DT
* W07.32899 CONTROL BOX ; WIRED ; PROGRAMMED THRI5-25SEP(DT)
* W07.32995 WIRING - TIMER THRI
* W07.34114 WIRED PROGRAMMED BOX THI 5-25/28 SEP GB/DK
* W07.34211 CONTROL BOX, PROGRAMMED, WIRED
* W07.34228 WIRED, PROGRAMM. CONTROL BOX THRI 5-25 M75H DC
* W07.34974 PROGRAMMED ; CONTROL BOX WIRING
* W07.35261 CONTROL BOX ; PROGRAMMED WIRING THI 2-17
* W07.35314 PROGRAMMED CONTROL BOX ; WIRING 2-17 B120
* W07.35319 PROGRAMMED CONTROL BOX ; WIRING 2-17 B120 DC
* W07.36535 WIRED & PROGRAMMED CONTROL BOX THI 5-25 B120 GB
* W07.36536 WIRED & PROGRAMMED CONTROL BOX THI 5-25 B120 DC
* W07.36930 CONTROL BOX ; WIRED ; PROGRAMMED
* W07.37986 SUPPLY CABLE 230V THRI
* W07.37991 CABLE TRANSFORMER+MASS THRI BURNER
* W07.37992 SWITCH CABLE THRI
* W07.37995 FAN CABLE THRI
* W07.37996 FAN CABLE THRI
* W07.37998 MASS CABLE THRI COVER
* W07.38000 SENSORS CONNECTION THRI
* W07.38001 CABLE PWM FOR THRI FAN
* W07.38002 FAN PWM CABLE THRI 10-50C
* W07.38004 SENSORS CONNECTION THRI 10-50 C
* W07.38379 FAN CABLE THRI/THISION/THI 10-50
* W09.37943 WIRING DHW SENSOR ZEM B120/SEP/M50
