7(&+1,&$/63(&,),&$7,216
  3,3(&211(&7,21',$0(7(56
- Combustion products Ø 80
- Gas inlet: PN 6 DN 40
- Heating flow: 2"1/2
- Heating return: 2"1/2
- Primary domestic water return 1"
- Primary domestic water flow 3/4"
- Condensate drain Ø 25
  ',0(16,216
605
67.5
92,1 152
354,1
404,6
457,1
553,1
225
180
197
263
270
625
1400
130 140
1000
1300
)LJ
Front view
Side view
View from above
