Part Numbers
80469, 87480, 85350, 86435, 86567
SPST, N.O. or N.C.
RED
RED
SPST
BLK
Part Number 83100
- Dry Condition -
120 VAC
YELLOW
GREEN
BLUE
ORANGE
BROWN
WHITE
SPST
BLK
Wiring Diagrams
Part Number 83110
- Dry Condition -
24 VDC
BLK
SPST
RED
YELLOW
GREEN
BLUE
ORANGE
BROWN
WHITE
RED
SPST
Part Numbers
83120, 83140, 83150
- Dry Condition -
SPST
BLK
2-COND.
CABLE
RED
Part Numbers
84320, 84330 SPDT
- Dry condition / J-Box at Top -
RED
WHT
BLK
3-COND.
CABLE
3‐PIN
TERM.
Part Number 83130
- Dry Condition -
RED
BLK
SPST
3‐PIN
TERM.
