4
后剪接收管
After sewing thread
cutter sensor(resieve)
光电自动检测
Electronic sensor self
check
抬压脚设定
Foot lifter setting
前剪针数设定
Before sewing thread
trimmer stitch no.
前剪起针速度设定
Before sewing thread
cutter speed
抬压脚抬起时间设定
Foot lifter up time
剪线完成误剪设定
Thread cut complete
setting
后剪针数
After sewing thread
cut stitch
安全开关设置
Safety switch setting
60
P-22
P-19
P-20
P-21
P-18
P-16
P-17
P-15
P-14
0
1
0
5000
20
4
0
0
0/1
5-50
0-50
0-50
150-8000
0-50
0-1
0-1
0-200
光电接收灵敏度调整;用户无需设置；
No need adjustment
0:自动检测薄厚布。1:人工检测，精准学习
0:auto testing.1:manual testing
0:开机无针位自选,1:自动选择上位针
0:NO position,1:Upper position
0:取消自动抬压脚,非自动 1:自动抬压脚;
0:No auto foot lifter 1:Auto-footlifter
前剪后剪速度限制;受P-00限制.
Before sewing and after sewing thread cutter
speed.
单位0.1秒（E2专用）;
Unit:0.1 second(E2 only)
0:开启;1:屏蔽;
0:Turn on;1:Off
后剪线头长短设定;单位1针
After sewing thread chain length setting;unit:1 stitch.
后剪结束到前剪检测延迟;单位0.1秒；
After sewing thread cut to before sewing thread
cut delay; unit:0.1second
前切开关设定
Before sewing switch
setting
前剪补针速度
Before sewing thread
cutter stitch add speed
P-23
P-24
P-25
P-26
P-27
0
0
0
2500
4
0-1
0-1
0-1
100-3000
0-5
后切开关设定
After sewing switch
setting
脚踏剪线开关设定
Pedal thread cutter
switch setting
0:自动感应;1:感应关闭;
0:Atuo;1:Off
0:开启;1:关闭;
0:On;1:Off
0:自动感应;1:感应关闭;
0:Atuo;1:Off
LED亮度设置
LED light brightness
setting
前剪超过显示速度时补针;用户无需设置;
No need adjustment
0:关闭;5:亮度最高;
0:Off;1:Max. brightness
4. 使用环境 要求 Operational Requirements
8).用户应具备合格的接地装置，以确保人身安全。
1).使用本系统时，应远离强磁场或高辐射环境，以免
受到干扰而发生误动作。
2).请不要室内温度高于40℃和低于5℃的环境下使用。
3).请不要在热源（暖气电热器）旁使用。
4).请不要在过潮过湿环境下使用。
5).请不要在有腐蚀性、爆炸性物质的环境下使用。
6).控制器及电机附近不可堆放杂物以免阻塞空气流通,
导致散热不畅。
7).用户供电电压应保持稳定。
fields and high environmental radiation in order to avoid
obstructions.
2).The operational temperature must be in the range of 50℃
-40℃ .
3). Please don’t use this product near to the origin of heat (
heat, radiator).
4). Please don’t use this product in over-wet circumstances.
5). Please don’t use this product near to corrosive liquids
and explosion.
6). Keep ventilation where the controller and motor stored.
7). Keep the power supply voltage steady.
8). There must be qualified connector to the ground in order
to make sure safety.
1). Please keep this system far away from high magnetic
