Secure the DCP Mounting Bracket to your existing
drum hardware. (The bracket has an embedded magnet
that makes mounting the DCP quick and easy.)
Place the Alignment Tab into the Alignment Channel on
the underside of the DCP (top first). The DCP fits into place
using an internal magnet.
Angle DCP to allow bracket alignment tab to slip into
alignment channel
Mounting DCP to Bracket
Alignment Channel
●
Bottom of DCP
●
Alignment Tab
●
DCP Mounting Bracket
●
