Orthoralix 8500 DDE
032-0253-EN Rev 39-6
Minimum Hardware Requirements
In order to ensure the proper operation of the Orthoralix 8500 DDE, it is
necessary that the associated computer hardware and software components
are properly selected and installed.
In particular, it is important to correctly configure the connection between the
Orthoralix 8500 DDE and a Personal Computer. In conformance with this, the
other electrically connected parts (Computer and optional peripherals) should
be located outside of the patient area and should be in conformity with IEC
950 and CE 89/336 Directive.
Computer
The computer configuration must include a CD-ROM drive along with Windows
Vista, Windows XP Professional, or Windows 2000 and the configuration as
required by the operating system installed.
Hard Disk
The choice of the hard disk depends on the number and size of the images to
be stored. A hard disk with 80GB or greater is usually able to satisfy a standard
user’s requirements. However, for data security, it is recommended to also
back up the stored information and diagnostic images.
Video Card
If not included in the computer, a S-VGA Video card with 1024x768 mode, and
has at least 4 MB RAM must be installed along with the accompanying
software.
Network Card
An Ethernet 10/100 base T network card must be installed.
Monitor
To ensure correct viewing of the images, a multisync colored monitor with high
resolution capable of displaying 800x600 min., or 1024x768 pixels, is
recommended. A flat screen monitor is preferred. The resolution is related to
the mode selected by the video card. Contrast and brightness must be
properly adjusted.
