1. Product Description.
The electro-pneumatic positioner is used for linear valve operations with pneumatic
actuators via an electric controller or control system using an analogue output signal of 4
– 20 mA.
This can be used on double or single effect actuators. Easy adjustment from zero to
span. Easy to change rotation (clockwise / anti-clockwise).
Low consumption of air and easy connection of air tubes.
2. Technical Data and Specifications
Positioner Technical Specifications
Input signal
4 ~ 20 mA DC
Impedance
250 ± 15Ω
Input pressure
1.4 ~ 7 kgf/cm
2
(20 ~ 100psi)
Stroke
Lineal 10 – 150 mm
Air connection
G (NPT)1/4”
Gauge connection
G (NPT)1/8”
Duct
M20 x 1.5
ATEX protection
Non-Explosion
Protection
IP66
Ambient temperature
-20°C ~ 70°C
Linearity
± 1.5 % F.S. (full scale)
Hysteresis
± 1.5 % F.S. (full scale)
Sensitivity
± 0.4 % F.S. (full scale)
Repeatability
± 0.5%
Air consumption
3 LPM (Sup =1.4kgf/cm
2
, 20psi)
Flow capacity
80 LPM (Sup =1.4kgf/cm
2
, 20psi)
Material
Aluminium alloy
Weight
2.8 kg (6.2 Ib)
