1.3) Parts list
Nº
Name
Material
Spare Part Code
1
Spring clip
Stainless steel AISI 304
------
2
Housing indicator
PC+ABS
------
3
Indicator
PC+ABS
------
4
Body
Al 6005-T5
------
5*
Guide piston
Techno - polymer
KGNP
6*
O-ring (pinion top)
NBR
KGNP
7*
Washer (pinion top)
Techno - polymer
KGNP
8*
Bearing (pinion top)
Techno - polymer
KGNP
9
Cam
Al. Steel
------
10
Pinion
Al. Steel
------
11*
Bearing (pinion bottom)
Techno - polymer
KGNP
12*
O-ring (pinion bottom)
NBR
KGNP
13*
Spring
AISI 301
C5800
14*
Ring (Piston)
Techno – polymer
KGNP
15*
O-ring (Piston)
NBR
KGNP
16*
Piston
Al. A380.1
EMB
17*
Plug
NBR
KGNP
18*
O-ring
NBR
KGNP
19
Adjust Nut
Stainless steel AISI 304
------
20
Adjust screw
Stainless steel AISI 304
------
21
Stop screw
Stainless steel AISI 304
------
22
Nut (stop screw)
Stainless steel AISI 304
------
23*
O-ring (End cap)
NBR
KGNP
24
End cap right
Al. A380.1
------
25
End cap left
Al. A380.1
------
26
Cap screw
Stainless steel AISI 304
------
27*
Spring clip
Stainless steel AISI 304
KGNP
28*
Washer
Stainless steel AISI 304
KGNP
29*
Ring
Techno - polymer
KGNP
* Available spare parts
2. Transport and Storage Conditions
The transport and storage of this type of product must be performed in its original
packaging!
