Genelec 5041A - System Specifications; Amplifier Section

ECDeclarationofConformity
This is to certify that the Genelec 5041A Active In-Wall
Subwoofer conform to the following standards:
Safety:
EN60065:2002+A1:2006/IEC60065:20017thEdition
+A1:2005
EMC:
EN55013(2001)+A1(2003)
EN55020(2002)+A1(2003)
EN61000-3-2(2000)+A2(2005)
EN61000-3-3(1995)+A1(2001)
The product herewith complies with the requirements of
TheLowVoltageDirective2006/95/ECandEMCDirective
2004/108/EC
Signed:
Ilpo Martikainen
Position: Chairman of the Board
Date: 25-September-2008
GenelecDocumentD0079R001CopyrightGenelecOy9.2008.Alldatasubjecttochangewithoutpriornotice
www.genelec.com
International enquiries:
Genelec,Olvitie5
FIN-74100,Iisalmi,Finland
Phone+3581783881
Fax+35817812267
Email genelec@genelec.com
In the U.S. please contact:
Genelec, Inc., 7 Tech Circle
Natick,MA01760,USA
Phone+15086520900
Fax+15086520909
Email genelec.usa@genelec.com
In Sweden please contact
Genelec Sverige
Ellipsvägen 10B
P.O.Box5521,S-14105Huddinge
Phone+4684495220
Fax+4687087071
Email info@genelec.com
In China please contact:
Beijing Genelec Audio Co. Ltd.
JianwaiSOHO,Tower12,Room2306
39 East 3rd Ring Road
ChaoyangDistrict
Beijing100022,China
Phone+86058697915,Fax+861058697914
5041AOperatingManual
AMPLIFIER SECTION
CONNECTORS
SYSTEM SPECIFICATIONS
5041A
Freeeldfrequencyresponse(±3dB) 35 Hz...95 Hz
MaximumshorttermsinewaveSPLoutput
averaged from 40 to 85 Hz, measured in half
space at 1 meter
105 dB
MaximumpeakSPLoutputwithrandompink
noise, measured in half space at 1 meter
110 dB
Self generated noise level in half space at 1 m
onaxis(A-weighted)
≤ 15 dB
Drivers 2x165mm(6.5")
Weight
Subwoofer enclosure
Amplier
15 kg (33 lb)
1.4 kg (3.1 lb)
Dimensions(seeFigure1)
Subwoofer enclosure
Height
Width
Depth
Amplier
Height
Width
Depth*
*Notethatthecableconnectorsrequireat
least100mm(4”)ofspacebehindthe
amplier
1170mm(46
1
/16”)
346mm(13
5
/8”)
82mm(3
1
/4”)
177mm(6
31
/32”)(4U)
54mm(2
1
/8”)
260mm(10
1
/4”)
5041A
Ampliershorttermoutputpower
(Long term output power is limited by driver
unit protection circuitry)
125W
AmpliersystemTHDatnominaloutput ≤ 0.05 %
Mains voltage 85-132Vor170-265V
according to region
Powerconsumption(average)
Stand by
Idle
Fulloutput
8.5VA
11VA
150VA
5041A
Input connector XLR female
pin 1
pin2
pin 3
1, balanced
gnd
+
-
Input connector RCA female
pin 1
pin2
1, unbalanced
gnd
+
LINKOUTconnectorXLRmale
pin 1
pin2
pin 3
1, balanced
gnd
+
-
Input impedance 10kOhm
LINKOUTgain 0 dB
CONTROLS
5041A
Input sensitivity +12to–6dBu
Phasematchingcontrolin90°steps From0to-270°
BassRoll-Offcontroloperatingrange
in2dBsteps
From0to-6dB@35Hz
Remote control Remote controlled
Standby/Onswitchingby
12Vtrigger
