COMPONENTS INCLUDED IN 0F4526E
1 0F1823 1 ENCL H CONTROL PANEL
2 0F1824 1 COVER CONTROL PANEL
3 0F2606 1 HINGE CONTINUOUS H-PNL
4 036261 6 RIVET POP .125 X .275 SS
5 0F5763 1 ASSY PROGRAMMED PM H-100
6 0F1732 1 DECAL FUSES LOCATED INSIDE
7 0E9764 1 RAIL SNAPTRACK PCB HOLDER BULK (12” LG)
9 0F1958 1 PLATE HARNESS CLAMP
10 0F2256 1 ASSY PCB PWR AVR W/AMP HEADER
11 0F5752A 1 RES WW 10R 5% 15W QK CONN
13 029673 1 DIO BRIDGE 25A 600V
15 049226 6 WASHER LOCK M5
16 079224 2 SCREW PPHM M5-0.8 X 30 SS
17 0D3876 6 WASHER FLAT M5
18 0F5886 3 SCREW HHPM M5-0.8 X 12
19 043182 1 WASHER LOCK M3
20 051714 1 NUT HEX M3-0.5 G8 YEL CHR
21 052777 1 WASHER FLAT M3
22 051716 3 NUT HEX M5-0.8 G8 CLEAR ZINC
23 043180 3 WASHER FLAT M4
24 0C3990 3 SCREW PHTT M4-0.7 X 10 ZYC
25 0F4333 1 CONN DUST CAP W/CHAIN DB9
26 0F5884 1 SCREW PHTT M3.5-0.6 X 10
27 0F5883 1 WASHER FLAT M3.5
28 055014 10 SCREW PPHM M4-0.7 X 8 BLK OX
29 043184 10 WASHER LOCK M4
30 0F2557 1 DECAL WARNING BATT CHRG 12/24V
31 0F6277 1 ASSY HARNESS H-PNL SW (NOT SHOWN)
32 0F6305 2 SEAL COVER 3.18 X 12.7 X 382
33 0F6305A 1 SEAL COVER 3.18 X 12.7 X 283
COMPONENTS INCLUDED IN WIRE HARNESS
A 0F1263 1 ADPTR RH SIDE WICKMAN 178.6191
B 0F1262 4 HOLDER FUSE WICKMANN 178.6150
C 0F1264 1 ADPTR LH SIDE WICKMAN 178.6192
D 0E9049A 2 ASSY PCB G-PANEL RELAY 24VDC
E 055911 1 BLOCK TERM 20A 12 X 6 X 1100V
COMPONENTS NOT INCLUDED IN 0F4526E OR WIRE HARNESS
50 082982 REF RELAY CONTACTOR 24VDC
51 022287 REF SCREW HHC 1/4-20 X 3/4 G5
52 022473 REF WASHER FLAT 1/4-M6 ZINC
53 022097 REF WASHER LOCK M6-1/4
54 022127 REF NUT HEX 1/4-20 STEEL
55 0E7403B 1 FUSE ATO TYPE 10 AMP (RED)
56 0E7403C 1 FUSE ATO TYPE 15 AMP (BLUE)
57 0F5772 1 DECAL H-100 RELAY BD 24V RB1
58 0F5773 1 DECAL H-100 RELAY BD 24V RB2
59 0F5459 1 DECAL CPL CONTROL PANEL FUSES
60 0F7582 2 DECAL 24VDC TB3
61 0C2323 2 SCREW PHTT #6-32 X 5/8 ZYC
62 0C2699 2 SCREW PHTT #6-32 X 3/8 ZYC
63 0F6145 A/R SEAL WEATHER .45" DIA
64 0F2627 1 PLATE COVER H PANEL
65 049226 4 WASHER LOCK M5
66 051713 4 WASHER FLAT M5
67 091526 4 SCREW PPHM M5-0.8 X 12 ZNC
68 048476 1 CB 4.5 X 1 AUT 30KW CNT 45K
69 043182 3 WASHER LOCK M3
70 051714 3 NUT HEX M3-0.5 G8 YEL CHR
71 052777 3 WASHER FLAT M3
72 0F5752D 1 RES WW 75R 5% 25W QK CONN
