Transceiver Installation - 2008 - 2012 with LCD Display
1. Locate the mounting feature and cover plate on the back of the generator. Remove the
cover plate, then position transceiver on the back of the generator ensuring the gasket
provides sealing.
MOUNTING LOCATION
Transceiver Mounting Location
2. Install 2 screws from inside the generator to secure the transceiver to the generator wall.
Transceiver Status
Light location
Transceiver Mounting Fasteners,
Transceiver Status Light Location and Wiring Connector
Installation
To Next Page
