Generac Power Systems 10 kW LP User Manual

PART 6
DISASSEMBLY
Page 154
Section 6.1
Major Disassembly
Figure 180.
Figure 181.
Figure 182.
MAJOR DISASSEMBLY
Safety:
1. Set the AUTO-OFF-MANUAL switch to OFF.
2. Remove the 7.5 amp main fuse. See Figure 183.
3. Remove the N1 and N2 fuses from the transfer switch.
Figure 183. Remove 7.5 Amp Fuse
4. Turn off fuel supply to the generator and remove the flex-
line from the fuel regulator.
5. Remove Utility power from the Generator.
6. Remove front door.
7. Remove battery from the generator.
