1
0F3137
1
PAN CB CONN BOX
2 0F3188 1 STAND RH CONTROL
3 0F3189 1 STAND LH CONTROL
4 023484N 1 BUSHING SNAP SB-2.5-31
5 0F6366B 1 XFMR DUAL 120V/16V (FOR 120/240V & 277/480V UNITS)
0F6366A 1 XFMR DUAL 104V/16V (FOR 120/208V UNITS)
6 043180 2 WASHER FLAT M4
7 022264 2 WASHER LOCK #8-M4
8 0C3990 2 SCREW PHTT M4-0.7 X 10 ZYC
(1) 9 057701 REF BLOCK TERM 20A 8 X 6 X 1100V
10 022155 4 WASHER LOCK #6
11 0C2428 4 SCREW PHTT #6-32 X 1/2 ZYC
12 0F3824 1 DECAL UTIL SENSE/CUST CONN
13 0A9457 1 DECAL NEUTRAL
14 057073 2 JUNCTION BLOCK 3/8-16
(2) 15 0D5466 REF BUS BAR NEUTRAL BLOCK 390
(2) 16 0A7822 REF LUG SLDLSS 600/250-1/0 X 1/4-28
17 022237 2 WASHER LOCK 3/8
18 022241 2 NUT HEX 3/8-16 STEEL
19 049226 4 WASHER LOCK M5
20 0C2266 4 SCREW PHTT M5-0.8 X 16 ZYC
21 0C2454 8 SCREW THF M6-1 X 16 N WA Z/JS
23 022473 8 WASHER FLAT 1/4-M6 ZINC
24 022097 4 WASHER LOCK M6-1/4
(1) 26 0D4698 REF BLOCK TERM 20A 6 X 3 X 1100V
27 0F4464 1 DECAL CUST CONN 120V UTILITY
28 025433 1 LUG SLDLSS #6-14 X 13/64 CU
29 024469 1 SCREW HHTT #10-32 X 3/8 CZ
30 067210A 1 DECAL GROUND LUG
31 0D6029 4 SCREW HHTT M6-1.0 X 16 ZYC
32 081008 1 GROMMET 1.25 X .25 X .75
33 077043J 1 CONDUIT FLEX 2.0" ID (36” LG)
34 051713 2 WASHER FLAT M5
35 0F6156 1 PLATE WIRE SNGL GALV
36 029289 1 TAPE ELEC 1/2 FOAM (AS REQ’D)
37 047411 4 SCREW HHC M6-1.0 X 16 G8.8
(3) 39 0G0770 1 HARNESS, TRANSFORMER ADAPTER
(4) 40 0G5952 1 ASSY PCB IGN MOD 4.2L
(4) 41 036943 2 SCREW PPHM #10/32 X 2
(4) 42 023897 4 WASHER FLAT #10 ZINC
(4) 43 022152 2 WASHER LOCK #10
(4) 44 022158 2 NUT HEX #10-32 STEEL
1) UL CIRCUIT BREAKER (ED)
A 0F3328 1 COVER ED CB SHORT STND
C 0D5552 1 CB 0050A 3P 480V S ED4 LL
0D5554 - CB 0070A 3P 480V S ED4 LL
0D5556 - CB 0090A 3P 480V S ED4 LL
0D9693 - CB 0125A 3P 480V S ED4 LL
D 0F0492 1 INSULATOR CB S (ED-3P)
E 048927 4 SCREW RHM #10-32 X 4-1/2
F 023897 4 WASHER FLAT #10 ZINC
G 022152 4 WASHER LOCK #10
H 022158 4 NUT HEX #10-32 STEEL
J 0C2454 7 SCREW THF M6-1 X 16 N WA Z/JS
K 029289 1 TAPE ELEC 1/2 FOAM (AS REQ’D)
L 0F1733 1 DECAL CUSTOMER CONNECT INSIDE
2) UL CIRCUIT BREAKER (FD)
A 0F3138 1 COVER CB CONN BOX
C 0D5572 1 CB 0150A 3P 600V S FD6 LL
0D5573 - CB 0175A 3P 600V S FD6 LL
0D5574 - CB 0200A 3P 600V S FD6 LL
0D5575 - CB 0225A 3P 600V S FD6 LL
0D5576 - CB 0250A 3P 600V S FD6 LL
D 0F0199 1 INSULATOR CB FD FRAME 30MIL
E 081320 4 SCREW SHC 1/4-20 X 4.5 G8.8 NZ
F 022473 4 WASHER FLAT 1/4-M6 ZINC
G 022097 4 WASHER LOCK M6-1/4
H 022127 4 NUT HEX 1/4-20 STEEL
J 0C2454 7 SCREW THF M6-1 X 16 N WA Z/JS
K 029289 1 TAPE ELEC 1/2 FOAM (AS REQ’D)
L
0F1733
1
DECAL CUSTOMER CONNECT INSIDE
3)
UL CIRCUIT BREAKER (JD+LD)
A 0F3329 1 COVER JD/LD CB SHRT STAND
C 0D5577 1 CB 0300A 3P 600V S JD6 LL
D 0F2353 2 INSULATOR CIRCUIT BR. JD/LD
E 022770 4 SCREW RHM 1/4-20 X 3
F 022473 4 WASHER FLAT 1/4-M6 ZINC
G 022097 4 WASHER LOCK M6-1/4
H 022127 4 NUT HEX 1/4-20 STEEL
J 0C2454 7 SCREW THF M6-1 X 16 N WA Z/JS
K 029289 1 TAPE ELEC 1/2 FOAM (AS REQ’D)
L 0F1733 1 DECAL CUSTOMER CONNECT INSIDE
4) UL CIRCUIT BREAKER (QN)
A 0F8135 1 COVER QN FRM CB
C 0E7283 - CB 0150A 2P 240V S QN2 LL
0E7284 - CB 0175A 2P S QN2 LL 240V
D 0E3664 1 BASE, QN CIRCUIT BREAKER
E 074908 2 SCREW HHTT M5-0.8 X 10 BP
F 0F8140 1 COVER QN CB DISH
G 036261 4 RIVET POP .125 X .275 SS
H 0C2454 7 SCREW THF M6-1X16 N WA Z/JS
J 029289 1 TAPE ELEC 1/2 FOAM (AS REQ’D)
K 0F1733 1 DECAL CUSTOMER CONNECT INSIDE
(1) ITEM INCLUDED WITH HARNESS
(2) ITEM INCLUDED WITH 0D5464B
(3) ITEM USED WITH EARLY MODEL 208V UNITS ONLY
(4) ITEMS USED ON 4.2L MODELS ONLY.
