1
N/A
N/A
UL BREAKER BQ2
A 0D5543 1 CB 0090A 2P 240V S BQ2 LL
0D5544 1 CB 0100A 2P 240V S BQ2 LL
0A2077 1 CB 0125A 2P 240V S BQ2 LL
B 0G4499 1 CB COVER 20-25K 1P (BQ2)
C 0C2265 2 SCREW PHTT M4-0.7 X 12 ZYC
D 0C2264 2 WASHER LOCK #8-M4
E 0E7890 1 BRKT CB MTG BACK
F 0G4497 1 CIRCUIT BREAKER SUPPORT (BQ)
G 052619 2 SCREW HHC M5-0.8 X 20 G8.8
H 023897 4 WASHER FLAT #10 ZINC
J 049226 2 WASHER LOCK M5
K 051716 2 NUT HEX M5-0.8 G8 CLEAR ZINC
L 0E3257 7 SCREW HWHTF M6-1.0 X 16
2 N/A N/A UL BREAKER BQ3
A 049135 1 CB 0070A 3P 240V S BQ3 LL
062812 1 CB 0080A 3P 240V S BQ3 LL
040532 1 CB 0100A 3P 240V S BQ3 LL
B 0G4500 1 CB COVER 20-25K 3P (BQ3)
C 0C2265 2 SCREW PHTT M4-0.7 X 12 ZYC
D 0C2264 2 WASHER LOCK #8-M4
E 0E6002 1 BRKT CB MTG BACK
F 0G4497 1 CIRCUIT BREAKER SUPPORT (BQ)
G 052619 3 SCREW HHC M5-0.8 X 20 G8.8
H 023897 6 WASHER FLAT #10 ZINC
J 049226 3 WASHER LOCK M5
K 051716 3 NUT HEX M5-0.8 G8 CLEAR ZINC
L 0E3257 7 SCREW HWHTF M6-1.0 X 16
3
N/A
N/A
UL BREAKER ED
A 0D5548 1 CB 0030A 3P 480V S ED4 LL
0D5549 1 CB 0035A 3P 480V S ED4 LL
0D5551 1 CB 0045A 3P 480V S ED4 LL
0D5552 1 CB 0050A 3P 480V S ED4 LL
0D5556 1 CB 0090A 3P 480V S ED4 LL
0D5557 1 CB 0100A 3P 480V S ED4 LL
0D9693 1 CB 0125A 3P 480V S ED4 LL
B 0G4502 1 CB COVER 20-30K 3P (ED)
C 066715 4 SCREW RHM #8-32 X 4-1/2
D 038150 4 WASHER FLAT #8 ZINC
E 022264 4 WASHER LOCK #8-M4
F 022471 4 NUT HEX #8-32 STEEL
G 0A8278 3 SCREW SHC 1/4-28 X 3/4 G8.8 NZ
H 022097 3 WASHER LOCK M6-1/4
J 0D5621 3 WASHER-STEP 1/2ODX9/32ID BRASS
K 0G4498 1 CIRCUIT BREAKER SUPPORT (ED)
L 0E3257 7 SCREW HWHTF M6-1.0 X 16
4 N/A N/A UL BREAKER QN
A 0E7283 1 CB 0150A 2P 240V S QN2 LL
B 0G3474 1 CONBOX FRONT COVER 1.6L QN 2P
C 074908 2 SCREW HHTT M5-0.8 X 10 BP
D 0E3257 7 SCREW HWHTF M6-1.0 X 16
E 0E3664 1 BASE, QN CIRCUIT BREAKER
F 0G4112 1 BREAKER SUPPORT BRACKET 30KW
5 0A1354A 1 REGULATOR - DC ALT
6 0G3473 1 CONBOX TOP PANEL SUPPORT
7 0F6366A 1 XFMR 208 TO 16V 6VA (208V. ONLY)
0F6366B 1 XFMR 240 TO 16V 6VA (240 / 480V.)
8 0G3524 1 COVER BELL HOUSING CONBOX
9 057701 1 BLOCK TERM 20A 8 X 6 X 1100V
10 0F3824 1 DECAL UTIL SENSE/CUST CONN
11 057073 1 JUNCTION BLOCK 3/8-16
12 057329 1 LUG SLDLSS 350-#6X13/32 AL/CU
13 0D4698 1 BLOCK TERM 20A 6 X 3 X 1100V
14 0F4464 1 DECAL CUST CONN 120V UTILITY
15 025433 1 LUG SLDLSS #6-14 X 13/64 CU
16 0G3472 1 CONBOX BACK & SIDES 1.6L
17 0E3257 22 SCREW HWHTF M6-1.0 X 16
18 0C2212 4 SCREW PHTT M4-0.7 X 16 ZYC
19 022264 9 WASHER LOCK #8-M4
20 022241 1 NUT HEX 3/8-16 STEEL
21 022237 1 WASHER LOCK 3/8
22 0C2265 5 SCREW PHTT M4-0.7 X 12 ZYC
23 023762 1 WASHER SHAKEPROOF EXT #10 STL
24 0A9457 1 DECAL NEUTRAL
25 0G4577E REF ASSY R-200 3600 1.6L
0G4578E REF ASSY R-200 1800 1.6L
26 047411 1 SCREW HHC M6-1.0 X 16 G8.8
27 022097 1 WASHER LOCK M6-1/4
28 049813 1 NUT HEX M6 X 1.0 G8 YEL CHR
5 N/A N/A UL BREAKER
A 0G5249 1 CB 150A 2 POLE 240V 225AF
* W/CB 2 TERMINAL COVER CB
B 0G5735 1 CB COVER 30K G 225AF
C 053640 2 SCREW RHM #8-32 X 3-1/4
D 038150 2 WASHER FLAT #8 ZINC
E 022264 2 WASHER LOCK #8-M4
F 022471 2 NUT HEX #8-32 STEEL
G 0F8432A 1 INSULATOR CB 2P 225AF
H 0G5734 1 CIRCUIT BREAKER SPPRT G 225AF
J 0E3257 8 SCREW HWHTF M6-1.0 X 16
K 049897 4 SCREW SHC M8-1.25 X 20 G8
L 022129 4 WASHER LOCK M8-5/16
M 022145 6 WASHER FLAT 5/16-M8 ZINC
N 058306 2 SCREW SHC M8-1.25 X 25 G12.9
P 045771 2 NUT HEX M8-1.25 G8 CLEAR ZINC
Q 0F8451 2 LUG SLDLSS 300 MCM-6 AL/CU
R 0F8843 2 BUS BAR 200A LUG ADAPTOR
