COMPONENTS INCLUDED IN 0G
1 0F1823A 1 ENCL HSB CONTROL PANEL
2 0F3078 1 COVER CONTROL PANEL
3 0F2606 1 HINGE CONTINUOUS H-PANEL
4 036261 6 RIVET POP .125 X .275 SS
5 0E7358 4 SCREW PPPH HI-LO #4-24 X 3/8
6 052777 3 WASHER FLAT M3
7 0G3958D 1 ASSY PCB R-200A CNTRL 3600
8 0F1262 REF HOLDER FUSE WICKMANN 178.6150
9 0F1263 REF ADPTR RH SIDE WICKMAN 178.6191
10 0F1264 REF ADPTR LH SIDE WICKMAN 178.6192
11 0F1725C 1 ASSY PCB 2AMP 12V UL BATT CHGR
12 067680 1 ASSY VOLTAGE REGULATOR 60HZ
13 0E6875A 2 RELAY 12VDC C FORM W/DIODE
14 055911 REF BLOCK TERM 20A 12 X 6 X 1100V
15 0F5459 1 DECAL CPL CONTROL PANEL FUSES
18 0F5462 1 DECAL CPL 3.9L TB1
19 0A5062J 4 SPACER 9.5H 3.2 ID
20 029673 1 DIO BRIDGE 25A 600V
21 049350 1 CIRCT BRK 4 X 1 ETA 46-500-P
22 0F1958 1 PLATE HARNESS CLAMP
23 082573 1 SWITCH RKR DPST 125V SPD
24 0E4494 1 SWITCH RKR DPDT ON-OFF-ON
25 0F3215 1 DECAL CONTROL HSB
26 0F6305 2 SEAL COVER 3.18 X 12.7 X 382
27 0F6305A 1 SEAL COVER 3.18 X 12.7 X 283
28 0F5886 3 SCREW HHPM M5-0.8 X 12
29 051713 14 WASHER FLAT M5
30 049226 14 WASHER LOCK M5
31 0F5752F 1 RES WW 15R 5% 25W QK CONN
32 0F5884 2 SCREW PHTT M3.5-0.6 X 10
33 0F5896 2 SCREW PHTT M3.5-0.6 X 16
34 0C2265 4 SCREW PHTT M4-0.7 X 12 ZYC
35 0C3990 2 SCREW PHTT M4-0.7 X 10 ZYC
36 091526 8 SCREW PPHM M5-0.8 X 12 ZNC
37 051716 7 NUT HEX M5-0.8 G8 CLEAR ZINC
43 043182 7 WASHER LOCK M3
44 051714 7 NUT HEX M3-0.5 G8 YEL CHR
45 0F3192 1 SUPPORT ANGLE PCB
46 0E7403C 1 FUSE ATO TYPE 15 AMP (BLUE)
47 0G4583 1 HARN CTRL PNL R-200 LOW KW (NOT SHOWN)
48 0F2627 1 PLATE COVER H PANEL
COMPONENTS INSTALLED PER THIS DRAWING
A 056739 1 RELAY SOLENOID 12VDC PNL MNT
B 022287 2 SCREW HHC 1/4-20 X 3/4 G5
C 022473 4 WASHER FLAT 1/4-M6 ZINC
D 022097 2 WASHER LOCK M6-1/4
E 022127 2 NUT HEX 1/4-20 STEEL
F 0F6145 A/R SEAL WEATHER .45"DIA
G 0G3545 1 DANGER HIGH VOLTAGE (SPANISH)
