2 075580 1 FLANGE FUEL INLET
3 0G1397A 1 FUEL REG. REWORK 1.6L 3600 '07 (3600RPM)
0G1397B 1 FUEL REG. REWORK 1.6L 1800 '07 (1800RPM)
4 039253 2 SCREW HHC M8-1.25 X 20 G8.8
5 022145 2 WASHER FLAT 5/16 ZINC
6 022129 4 WASHER LOCK M8-5/16
7 045771 2 NUT HEX M8-1.25 G8 YEL CHR
(1) 8 0F1570 1 BODY CARBURETOR ASSEMBLY
9 0A6344 1 BARBED EL 90 1/8 NPT X 3/8
10 0C5210 1 HOSE 3/8 ID LOW PRES OIL/WATER (16” LG)
11 025424 1 NIPPLE PIPE 3/4 NPT X 6
12 0C5210 1 HOSE 3/8 ID LOW PRES OIL/WATER (12” LG)
13 0A5547 1 COVER AIR CLEANER
14 0G3178 1 HOSE BREATHER 1.6L
15 0D1509 1 DECAL INLET PRESSURE
ADAPTER CARB. TO AIR CLNR
17 059402 1 FILTER ELEMENT
18 037561 1 NUT WING 1/4-20 NYLK
19 0E1028F 1 ASSY CARBURETOR 1.6L 3600RPM
0E1028E 1 ASSY CARBURETOR 1.6L 1800RPM
20 059401 1 CARBURETOR GASKET
(1) 21 091526 4 SCREW PPHM M5-0.8 X 12 ZNC
(1) 22 049226 4 WASHER LOCK M5
23 026915 2 NIPPLE CLOSE 3/4 X 1.375
24 062522 1 STUD TH 1/4-20 X 3 G2 ZNC FULL
25 022127 1 NUT HEX 1/4-20 STEEL
(1) 26 0E1339 1 PIN SPRING 3/16 X 5/8
(3) 27 050279 1 DECAL FUEL INLET NG
050280 1 DECAL FUEL INLET LPG
28 030795 2 SCREW HHC 5/16-18 X 1 G5
29 0F6155 1 HARNESS FUEL JUMPER SINGLE REG
(1) 30 0E1104 1 GASKET AIR CLEANER ADAPTER
(1) 31 0E0668 1 O-RING 2-028 1.38 X 1.50 X .06
(1) 32 0E0590A 1 VENTURI 20MM (3600RPM)
0E0590 1 VENTURI 18MM (1800RPM)
(1) 33 0C5133 1 O-RING 29.82 X 2.62
(1) 34 0E0665 1 SCREW THROTTLE PIN STOP
(1) 35 0E1108 1 THROTTLE ARM REWORK
(1) 36 033138 1 SCREW HHM #10-32 X 5/8
(1) 37 022152 1 WASHER LOCK #10
(1) 38 0E0645 1 LEVER THROTTLE STOP
(1) 39 034339 1 BARBED EL 90 3/8 NPT X 5/8
40 059194 1 HOSE 5/8 ID LPG & NG (12” LG)
41 057823 2 CLAMP HOSE #10 .56 - 1.06
42 026073A 1 PLUG STD PIPE 1/4 STEEL SQ HD
43 048031L 4 CLAMP HOSE BAND 1.0"
44 048031J 4 CLAMP HOSE BAND .63
46 0G1985 1 HOSE BARB REDUCR TEE 3/4"-3/8"
47 0F3994 1 PCV VALVE 2.5L FORD
(1) 49 0E0568 1 SHAFT THROTTLE 1.5L
(1) 50 0E0527 1 THROTTLE VALVE PLATE 27MM
(1)(2) 51 025105 1 SCREW RHMS 6-32 X 1/4 ZINC
(1) 52 0E0991 1 SEAL SHAFT COVER
53 048031P 1 CLAMP HOSE BAND .88"
(1) INCLUDED IN ITEM 19 (CARBURETOR ASSY )
(2) APPLY LOCTITE TO I/N 51 BEFORE THREADING INTO
I/N 49.
(3) FOR LP VAPOR APPLICATION SUBSTITUE LPG FUEL
INLET DECAL P/N 050280 FOR NG FUEL INLET DECAL P/N
050279 (ITEM 27).
NOTES:
1. REGULATOR (I/N 3) AS SHOWN IN ILLUSTRATION IS SET
UP FOR NATURAL GAS APPLICATION.
2. TO CONFIGURE REGULATOR FOR LP VAPOR, REFER
TO THE “RECONFIGURING THE FUEL SYSTEM” SECTION
OF THIS MANUAL.
