4
High Pressure Washer
KNOW YOUR PRESSURE WASHER
Read this owners manual and safety rules before operating your high pressure washer. Com-
pare the illustrations with your high pressure washer to familiarize yourself with the locations of various controls
and adjustments. Save this manual for future reference.
Generac 3000PSI High Pressure Washer
Pump Develops high pressure.
Recoil Starter Used for starting the engine manu-
ally.
Spray Gun Controls the application of water and
chemical onto cleaning surface with trigger device.
Includes safety latch.
High/Low Pressure Handle The handle allows you
to select the high pressure spray or the chemical spray.
Dual Element Air Cleaner Uses a dry type filter
element and foam pre-cleaner to limit the amount of
dirt and dust that gets in the engine.
Choke Used when starting a cold engine.
Water Inlet Connection for garden hose.
Dual Lance Must be connected to the spray gun.
Spark Arrestor Muffler Exhaust muffler lowers
engine noise and is equipped with a spark arrestor
screen, a USDA mandate for engine use in national
forests and parks.
High Pressure Outlet Connection for high pressure
hose.
High Pressure Hose Connect one end to water
pump and the other end to spray gun.
Goggles Always use the enclosed goggles or other
eye protection when running your pressure washer.
Automatic Cool Down System Cycles water
through pump when water reaches 140°-145°F. Warm
water will discharge from pump onto base of unit.
This system prevents internal pump damage.
Pressure Control Knob Rotated to switch between-
high and low pressure. Low pressure must be used
when applying detergent.
High/Low Pressure
Handle
Gas Tank
Dual Lance
Choke
Spray Gun
Water Inlet
Pump equipped with
Automatic Cool Down System
High Pressure Outlet
High Pressure Hose
Pressure Control
Knob
Spark Arrestor
Muffler
Dual Element
Air Cleaner
Recoil Starter
Goggles
GENERAC
The Reliable Ones
