USING THE NOZZLES
The chemical nozzle, which is permanently affixed to
your dual lance and has a spray pattern of 25
degrees, must be used when applying chemical. The
other nozzle attached to the lance has a 15 degree
spray pattern and is used when rinsing. There are
four accessory nozzles that may be purchased that
are used when rinsing. Each has a different spray
pattern, as indicated in the following illustration
(Figure 8).Please note that if you choose to purchase
these nozzles, you must also buy a quick connect
adaptor.
In order to change the accessory nozzle being used,
simply pull back the collar on the quick connect and
pull the current nozzle off. To put one on, pull back
the collar, insert the new nozzle and release the
collar, making sure it becomes flush with the end of
the quick connect. This procedure is only used when
utilizing the accessory nozzles that may be pur-
chased.
CHECKLIST BEFORE
STARTING ENGINE
If you have reached this point, look back over the
assembly to see if you have performed all of the fol-
lowing.
Check for properly tightened hose connections
(high pressure and water supply) and for tight con-
nections and that there are no kinks, cuts, or
damage to the high pressure hose, or garden hose.
Check that oil has been added to proper level in
engine crankcase before trying to start the pressure
washer.
Add proper gasoline to fuel tank.
Provide proper water supply (not to exceed 140°F).
Be sure to read Safety Rules and Operation sec-
tions before using the pressure washer.
Figure 8 — Spray patterns of nozzles
Generac 3000PSI High Pressure Washer
AASSSSEEMMBBLLYY
8
