Generac 3000PSI High Pressure Washer
AA
SSSSEEMMBBLL
YY
7
High Pressure Washer
Connect Hose and Water
Supply to Pump
IMPORTANT: You must connect the gun to the dual
lance and attach all hoses before you start the
engine. Starting the engine without all hoses con-
nected and the water supplied will damage the pump.
Uncoil the high pressure hose and attach the end of
the hose with the quick connect to the base of the
spray gun (Figure 4). Tighten by hand.
Attach the other end of the high pressure hose to
the high pressure outlet on the pump (Figure 5).
Tighten by hand.
Before you connect your garden hose to the water
inlet, inspect the water inlet screen (see Figure 6).
Clean the screen if it contains debris or have it
replaced if damaged. Do not run the pressure
washer if the water inlet screen is damaged.
Connect the garden hose to water inlet. Tighten
firmly by hand (Figure 6).
Turn on the water (open valve completely).
Squeeze the trigger on the gun to purge the pump
system of air and impurities. Squeeze until a steady
stream appears.
Attach the dual lance to spray gun. Tighten by
hand (Figure 7).
Warning: Before starting the pressure
washer, be sure you are wearing ade-
quate eye protection.
Figure 5 — Connect high pressure hose to
pump.
Figure 4 — Connect high pressure hose
to spray gun.
Figure 6 — Connect garden hose to water inlet
and turn ON water.
Connect High Pressure
Hose Here
Figure 7 — Connect dual lance to spray gun.
GENERAC
The Reliable Ones
