4000XL Extended Life Generator
21
PARTS LIST – MAIN UNIT
Item Part # Description
1 M189159GS CRADLE
2 M84021GS SUPPORT, Engine, Red
3 NSP ENGINE
4 66365GS HOUSING, Engine Adapter
5 84141JGS ASSY, Rotor (Includes Item 7)
6 83540JGS ASSY, Stator
7 65791GS BEARING
8 96796GS WASHER
9 73054GS DECAL, Fuel Shut Off
10 86307GS SCREW
11 47480GS SCREW
12 84508GS MOUNT,Vibration
13 B2153GS SCREW
14 83208GS BRACKET, Muffler
15 B4986GS DECAL, Ground
16 66476GS SCREW
17 89476GS GASKET, Exhaust
18 70644GS SCREW
19 84346GS SCREW
20 40976GS SCREW
21 83083GS SCREEN, Spark Arrest
22 83071GS MUFFLER
23 81917GS PIN, Roll
24 77816GS DECAL, Caution Hot Muffler
25 SRV66825DGS CARRIER, Rear Bearing
26 85652GS MOUNT,Vibration
27 67989GS NUT
28 26850GS WASHER
29 84409GS SLEEVING, Flexo
30 74908GS SCREW
31 87116GS ASSY, Control Panel (see page 22)
32 86308GS BOLT
33 65795GS RECTIFIER, Battery Charge
34 66849AGS SCREW
35 67022GS GROMMET, Rubber
36 84132GS ASSY, Drive Module Pwr Reg.
37 66386GS ASSY, Brush Holder
38 66849GS SCREW
39 B4871GS COVER, Bearing Carrier
Item Part # Description
40 22145GS WASHER
41 86494GS SCREW,Wing
42 86292GS SCREW
43 52858GS NUT, Lock
44 189134GS GROMMET,Tank
45 93826GS DECAL, Operating Instructions
46 51731GS SCREW
47 189133GS VALVE,Tank (Includes Item 48)
48 189759GS KIT, Fuel Valve Repair
49 189135GS CAP,Tank Fuel,Vented
50 193574GS ASSY,Tank, Fuel
(Includes Items 47 & 48)
51 J84042GS SHIELD, Heat
52 84687GS INSULATION
53 85000GS CLIP, Insulation
54 14353621GS WIRE, Ground
55 23762GS WASHER
56 189568GS CLAMP, Hose
57 92982GS DECAL, Danger
58 B1797GS CLIP,Tree
59 189137GS SPACER
Items Not Shown:
BB3061GS OIL BOTTLE
43483GS PLUG, 250V 20A 4-Prong
37806GS PLUG, 125V 30A 3-Prong
70185GS OIL FILTER
78601GS AIR CLEANER
65787GS CABLE, Battery Charge
193524GS MANUAL, Owners
A8926GS MANUAL, Engine
84882GS WRENCH, Spark Plug
72347GS SPARK PLUG
84895GS COVER, Storage
193575GS KIT, Decals
Optional Accessories Not Included:
84883GS Cord Wrap
