Generac Portable Products 5500EXL Extended Life Generator
17
PARTS LIST
Item Part # Qty. Description
1 A92432 1 CRADLE
2 A92531 1 SUPPORT, Engine
3 A92731 1 SUPPORT, Engine & Muffler
4 92247 1 HOUSING, Engine Adapter
5 92678G 1 ASSEMBLY, Rotor
6 94980A 1 ASSEMBLY, Stator
7 65791 1 BEARING
8 67451 1 WASHER, Special Flat - M8
9 22129 16 WASHER, Lock - M8
10 86307 4 HHMS, 5/16-24 x 3/4
11 28092 1 HHCS, 5/16-24 x 9-1/4
12 92609 2 MOUNT, Vibration
13 82857 4 MOUNT, Vibration
14 92532 1 BRACKET, Muffler
15 90239 1 GASKET, Muffler
16 66476 2 CAPSCREW, M6 - 1.0 x
12mm
17 A7433 1 MUFFLER
18 40976 2 SCREW, M8 - 1.25 x 20
19 83083 1 SCREEN, Spark Arrester
20 81917 1 PIN, Roll 4mm x 10
25 66825C 1 CARRIER, Rear Bearing
26 74908 4 TAPTITE, M5-0.8 x 10
27 86308A 4 BOLT, Stator M6-1 x 145mm
28 65795 2 RECTIFIER, Battery Charge
29 66849C 1 TAPTITE, M5-0.8 x 30
30 67022 1 GROMMET, Rubber
31 84132 1 ASSEMBLY, Power Regulator
32 66386 1 ASSEMBLY, Brush Holder
33 66849 2 TAPTITE, M5-0.8 x 16
34 B67025 1 COVER, Bearing Carrier
35 22769 1 WASHER, Shakeproof Int. #10
36 86494 1 SCREW, M6-1.0 x 16 Wing
37 86292 1 HHCS, - #10 Self Driller
38 77395 4 NUT, Flange Lock - M6
39 83465 4 GROMMET, Tank
40 57058 4 HHCS, M6-1.0 x 55
41 80270 1 VALVE, Tank
42 78299 1 BUSHING, Tank
43 B4363 1 CAP, with Gauge, Fuel
44 B1695 1 TANK, Fuel 7 Gal.
45 B92039 1 SHIELD, Heat
Item Part # Qty. Description
46 92665 1 INSULATION, #2-1/4" Thick
47 85000 1 CLIP, Insulation
48 14353621 1 WIRE, Ground
49 26850 2 LW, EXT, Shakeproof M6
51 92982 1 DECAL, Danger
52 96057 2 DECAL, Heat Shield
55 25244 12 NUT, 5/16-18 Hex
57 96058 1 DECAL, Control Panel
58 92630 1 ASSEMBLY, Control Box
59 NSP 1 ENGINE
60 22531 2 HHCS, 5/16-18 x 1-3/4"
61 22142 2 SCREW, 5/16-18 x 3/4"
62 77282 1 SWITCH, Starter
63 22287 2 SCREW, 1/4 - 20 x 3/4
64 22097 2 LOCKWASHER, M6
65 22127 2 NUT, 1/4 - 20 Hex
66 78289 1 BRACKET, Starter Switch
67 93826 1 DECAL, Start Instructions
68 B96068 1 SHIELD, Heat
69 56893 5 CRIMPTITE, 10-24 x 1/2
70 B2153 8 SCREW, #12 Self Drill
71 22473 4 WASHER, Flat M6
Parts Not Illustrated:
37806 1 125V 30A Locking plug
43438 1 240V 30A Locking plug
72347 1 Spark plug
73111 1 Air cleaner element
84882 1 Spark plug wrench
20820 1 Owners manual
65787 1 Battery charge cable
Battery Tray Components:
22129 2 Lockwasher, M8
45771 2 Hex nut M8
96925 1 Battery tiedown
96924 2 J-bolt
15453621 1 Battery cable, positive
15553621 1 Battery cable, negative
96923 1 Battery tray
22145 2 Flat washer
58443 4 Screws, battery tray
To Next Page
