Section 2 General Information
2.1 — The Generator
Figure 2-1: GH-410 Engine 8 kW Unit
Figure 2-2: GH-530 Engine 11 kW Unit
EXHAUST
E
NCLOSURE
COMPOSITE BASE
OIL FILTER
OIL FILL CAP
BATTERY COMPARTMEN
T
FUEL
REGULATOR
CIRCUIT
BREAKERS
FUEL INLET
(BACK)
CONTROL
PANEL
OIL
DIPSTICK
AIR FILTER
DATA LABEL
(SEE SAMPLE)
EXHAUST
ENCLOSURE
COMPOSITE BASE
OIL FILTER
OIL FILL CAP
BATTERY COMPARTMENT
FUEL
REGULATOR
CIRCUIT
BREAKERS
FUEL
INLET
(BACK)
CONTROL
PANEL
OIL
DIPSTICK
AIR FILTER
DATA LABEL
(SEE SAMPLE)
