Generac Power Systems GENERAC 0H0923PMNL User Manual

9
6.8L Gas EngineTiming Cover
ITEM PART NO. DESCRIPTION QTY
6019 0D34540205 COVER & GASKETS, FRONT 1
6020 0D34540206 GASKET, FRONT COVER, LH 1
6020 0D34540207 GASKET, FRONT COVER, CENTER 1
6020 0D34540208 GASKET, FRONT COVER, RH 1
6B288 0D34540230 SENSOR, CAM 1
6C315 0F73160110 SENSOR, CRANK 1
6700 0D34540217 TIMING COVER CRANKSHAFT SEAL 1
HB1 0F19600134 SCREW/WASHER, FRONT CVR, M10X1.5X103.1 3
HB2 0F73160125 BOLT, FRONT COVER, M8X1.25X53 A/R
NOT SHOWN 0F19600135 STUD, FRONT CVR, M10X1.5X1.5X103.1 2
HS1 0F73160111 BOLT, CAM AND CRANK SENSORS TO TIMING CVR, M6X1.0X27.5 2
HT1 0F19600236 STUD, WASHER, FRNT CVR, M10X1.5/M8X1.25X106.7 5
Note: The right and left banks of engine are determined by viewing the engine from the flywheel side.
