25
6.8L Gas Engine Intake Manifold
Note: The right and left banks of engine are determined by viewing the engine from the flywheel side.
ITEM PART NO. DESCRIPTION QTY
6026 0D34540103 PLUG, 3/8"-18 X .425 PIPE PLUG 1
9424B 0H09230110 MANIFOLD, INTAKE, LOWER, ALUMINUM (NOT REP.11-07) 1
9424A 0H09230119 MANIFOLD, INTAKE, UPPER 1
9229 0H09230152 SEAL 1
NOT SHOWN 0D34540240 CAP, TUBE, 1/4" INT. MANIFOLD HEATER INLET, FRONT 1
9439 0D34540247 GASKET, INTAKE MANIFOLD TO CYLINDER HEAD 2
9461A 0H09230135 GASKET, “A”, UPPER TO LOWER PLASTIC INT. MNFLD. 8
9461B 0H09230136 GASKET, “B”, UPPER TO LOWR PLASTIC INT. MNFLD. 1
9461 0H09230177 GASKET, ONE PIECE, UPPER TO LOWER, ALUM, INT MNFLD. 1
HB1 0F73160178 BOLT, UPPER INTAKE TO CYL.BLOCK, M8X1.25X43MM 11
HS1 0F7316B170 BOLT, M6X1.0X42.5, UPPER TO LOWER INTAKE MANIFOLDS 10
NOT SHOWN 0F97650210 ISOLATER ASY /SCREW TO INTAKE MANIFOLD A/R
