6.8L Gas Engine Piston, Rod and Crank
ITEM PART NO. DESCRIPTION QTY
6108 0F19600136 PISTON, STANDARD 10
6108 0H09230204 PISTON, .010"/.25MM 0/S A/R
6108 0H09230205 PISTON, .020/.50MM O/S A/R
6135 0F19600137 PIN, PISTON 10
6140 0D34540113 RETAINER, PISTON PIN 20
6148 0F19600138 RINGSET, STANDARD(SET IS FOR 2 PISTONS) 5
6148 0F1960A143 RINGSET, .010/.25MM O/S A/R
6148 0F1960A144 RINGSET, .020"/.50MM O/S A/R
6200 0F1960A153 ROD ASSY., CONNECTING 10
6214 0D34540120 BOLT, CONNECTING ROD 20
6207 0F19600139 BUSHING, PIN 10
6211 0F73160117 BEARING, ROD, STANDARD 20
6211 0F1960A141 BEARING, ROD, .020"/.50MM UNDERSIZE A/R
6303 0D34540122 CRANKSHAFT 1
6D309 0F19600142 BEARING KIT, MAIN, STANDARD GRADE 1 A/R
6D309 0F1960A120 BEARING KIT, MAIN, STANDARD GRADE 2 A/R
6D309 0F1960A121 BEARING KIT, MAIN, STANDARD GRADE 3 A/R
6D309 0H09230121 BEARING KIT,MAIN .010"0R .25MM U/S, GRADE 1 A/R
6D309 0H09230122 BEARING KIT,MAIN .010"0R .25MM U/S, GRADE 2 A/R
6D309 0H09230123 BEARING KIT, MAIN .010" OR .25MM U/S GRADE 3 A/R
6D309 0H09230224 BEARING KIT, MAIN, .020" OR .50MM, UNDERSIZE A/R
6D309 0H09230209 BEARING KIT, MAIN, .030" OR .75MM UNDERSIZE A/R
6701 0D34540126 SEAL, CRANKSHAFT REAR OIL 1
6K301 0F73160148 RETAINER, REAR OIL SEAL 1
NOT SHOWN 0F97650111 PIN,DOWEL,REAR CRANKSHAFT SEAL RETAINER 2
NOT SHOWN 0F73160111 BOLT, REAR CRANKSHAFT SEAL RETAINER, M8X1.0X27.5 6
6306 0D34540216 GEAR, CRANKSHAFT TIMING 1
6B316 0F73160147 KEY, WOODRUFF, CRANKSHAFT, 3/16"X1.40" 1
6310 0F19600146 SLINGER, REAR CRANKSHAFT, OIL 1
Note: The right and left banks of engine are determined by viewing the engine from the flywheel side.
