6.8L Gas Engine Timing Gears
Note: The right and left banks of engine are determined by viewing the engine from the flywheel side.
ITEM PART NO. DESCRIPTION QTY
6K255 0D34540209 `ARM, TIMING CHAIN, TENSIONER, RH 1
6M256 0F19600147 GUIDE, TIMING CHAIN, RH 1
6L266 0D34540211 TENSIONER, TIMING CHAIN, LH 1
6L266 0D34540212 TENSIONER, TIMING CHAIN, RH 1
6256 0D34540190 GEAR, CAM RH 1
6256 0D34540191 GEAR, CAM LH 1
6268 0F19600150 CHAIN, TIMING 2
6M274 0D34540214 ARM, TIMING CHAIN TENSIONER, LH 1
6K297 0F19600152 GUIDE, TIMING CHAIN, LH 1
6278 0D34540193 WASHER, CAMSHAFT, 13.5X48.5X5.3 1
6279 0D34540204 BOLT, CAM SPROCKET, M10X1.5X47.5, HEX HEAD 2
6306 0D34540216 SPROCKET, CRANK 1
NOT SHOWN 0H09230172 RING, IGNITION PULSE, CRANK PULSE SENSOR 1
HB4 0E96180124 BOLT, TIMING CHAIN GUIDES, 1LH,2RH, M6X1.0X22.5 3
HB3 0D34540220 BOLT, TIMING CHAIN GUIDES, LH, M6X1.0X67.5 1
HB2 0H09230203 BOLT, TENSIONER, M8X1.25X53 4
HB1 0D34540221 BOLT M8 X 1.25 X 53MM A/R
6P250 CONTACT PARTS 2
