— 15 —
GGeenneerraacc GGNN--557700 EEnnggiinnee
RReeppaaiirr PPaarrttss LLiisstt –– 1199 hhpp VV--TTwwiinn
ITEM GENERAC NO. SEE NOTE DESCRIPTION
1 100-92134 Cylinder Assembly
2 100-85110 Bushing
3 67805 * Seal, Oil
5 101-92134 Head, Cylinder #1
5A 102-92134 Head, Cylinder #2
7 103-92134 *+ Gasket, Cylinder Head
8 104-85110 Breather Assembly
9 72315 * Gasket, Breather (incl. #722)
10 105-85110 Screw, Shoulder
11 70596 Tube, Breather
12 69336 * Gasket, Crankcase
13 69325 Screw, Hex
15 67888 Plug, Oil Drain
16 C2796 Crankshaft
106-85110 Timing Gear Key
107-85110 Thrust Washer
17 108-85110 Bearing, Ball
18 70540 Cover, Crankcase
20 67924 * Seal, Oil
22 109-85110 Screw, Hex
23 C2880 Flywheel
24 112-85110 Key, Flywheel
25 107-92134 Piston Assembly (std)
108-92134 Piston Assembly (.010 o/s)
109-92134 Piston Assembly (.020 o/s)
110-92134 Piston Assembly (.030 o/s)
26 111-92134 Ring Set (std)
112-92134 Ring Set (.010 o/s)
113-92134 Ring Set (.020 o/s)
114-92134 Ring Set (.030 o/s)
27 69327 Lock Pin, Piston
28 115-92134 Pin, Piston
29 119-85110 Rod, Connecting (std)
120-85110 Rod, Connecting (.020 o/s)
32 72346 Screw, Hex
33 69316 Valve, Exhaust
34 69317 Valve, Intake
35 121-85110 Spring, Valve
37 102-85109 Guard, Flywheel
39 123-85110 Deflector, Oil
40 69320 Retainer, Valve
42 70513 Keeper, Valve
45 124-85110 Tappet, Valve
46 70530 Gear, Cam
50 125-85110 Manifold, Intake
50A 103-85109 Manifold, Exhaust (man. start)
To Next Page
