— 17 —
GGeenneerraacc GGNN--557700 EEnnggiinnee
RReeppaaiirr PPaarrttss LLiisstt –– 1199 hhpp VV--TTwwiinn
ITEM GENERAC NO. SEE NOTE DESCRIPTION
206 152-85110 Nut
207 153-85110 Spring, Control Rod
208 154-85110 Rod Control
209 77348 Spring, Governor
209A 79282 Spring, Governor Idler
216 157-85110 Link
216A 158-85110 Rod, Choke
222 130-92134 Bracket, Control
227 72320 Lever, Governor
232 70125 Spring, Link
239 60108 Switch, Oil Pressure
240 160-85110 Filter, Fuel
243 70531 Screen, Oil Pump
265 131-92134 Clamp, Casing
271 161-85110 Lever, Control
277 67884 Washer, Flat M6
277A 132-92134 Washer
280 163-85110 Bracket, Rod
300 164-85110 Muffler, Exhaust
304 133-92134 Housing, Blower
305 66886 HHCS/LW M6-1.0 x 12 mm
307 67898 HHCS/LW M8-1.25 x 16 mm
307A 105-85109 Screw, Hex
308 168-85110 Cover, Air Guide (cyl #1)
308A 169-85110 Cover, Air Guide (cyl #2)
309 C2881 Motor, Starter
310 C2883 Screw, Hex
332 171-85110 Nut, Flywheel
333 67891 Armature, Magneto
334 72356 HHCS/LW M4 x 7 mm
337 72347 Plug, Spark
346 134-92134 Screw, Hex
351 20169 Screw,Phillips Hex
351A 173-85110 Screw, Hex
353 174-85110 Washer, Lock
353A 175-85110 Washer, Lock
354A 176-85110 Nut, Hex
356 193-85110 Wire, Stop
356A 137-92134 Wire, Stop
357 138-92134 Key, Drive Pulley
358 139-92134 Gasket, Set
363 177-85110 Flywheel Puller
383 178-85110 Wrench, Spark Plug
423 66484 Screw, Phillips Hex
