Owner’s Manual for Portable Generator 21
Item
Number
Part Number Description Qty.
1 10000031471 Intake Plenum 1
2 10000031472 Air Plenum to Carb Gasket 1
3 10000031504 Carburetor Assembly 1
4 10000031511 Stepper Motor 1
5 10000031466 Carb to Spacer Gasket 1
6 10000031473 Carburetor Spacer 1
7 10000031530 Rocker Cover Gasket 1
8 10000031505 Spark Plug 1
9 10000031531 Intake Port Gasket 1
10 10000031483 Breather Tube 1
11 10000031467 Recoil Assembly 1
12 10000031484 Air Cleaner Element 1
13 10000031494 Ignition Coil 1
14 10000031469 Recoil Cup 1
15 10000031506 Fuel Inlet Tube 1
16 10000031521 Hose 1
17 10000031540 Engine Oil Dipstick 1
18 10000031475 Muffler Assembly 1
19 10000031513 Muffler Gasket 1
20 10000031476 Exhaust Pipe 1
21 10000031522 Exhaust Port Gasket 1
