SECTION 4:
GOVERNOR
CONTROLS AND GOVERNOR
3. Adjust stop screw to maintaln 1200 RPM idle
4.
slowly
move
speed control lever to high-speed
position.
Do not exceed 4000 RPM.
Nol€: The high-speed
screw may need adjusting to rcach
the
speed .ontrol stop without exceeding 4000 RPM.
5. Wth the speed controljn the high-speed
position,
adjust
the high-speed
screw io obiain the desired engine speed.
Figurc 4-5.
Dynamic Govenot Adjustnent
4-3
