SECTION
10: CYLINDER &
CRANKCASE COVER
INSTALL PTO OIL SEAL:
lnstalla new fio oilsealand
press
itin und h is 1.5mm(l/16")
below the mounting surface.
CHECK
CAMSHAFI BEARINGS
lJse
a telescoping
gauge
and caliperto check camshaft beaF
ings. lf
camshaft
bearings are woTn, crankcase or crankcase
cover must be replaced.
(Forveatical
shaft engines, the
gero-
Mag Bearing Reject Dimension:
20-06mm
(.790")
PfO Beafing Rejed Dimension: 18.06mm
(7rr')
O]L SEALS:
Always
installnew oil
seals
whenever
engine
i5 dlsaslembled
for major servicinq or when repai ng bearings, Lub cate 5eal-
ing edge of oil seal with clean engine oil before assembly.
Alw;ys use the correct seal
protectorto prevent
damaging oi
seal.
Figurc 10-11. Chec*ing Mag Side Camshaft Beaing
Figurc 10-10. Che&ing PfO Side Canshaft Beaing
I0-4
