ITEM PART NO. QTY. DESCRIPTION
1 0E8411 1 INTAKE DUCT HSB
2 0E8042 1 DUCT DISCHARGE RH FRONT
3 0E8041 1 DUCT DISCHARGE LH FRONT
4 0C2454 62 SCREW TH-FRM M6-1 X 16 N WA Z/JS
5 0E7807 1 BAFFLE REAR BOTTOM
6 0E7808 1 POST CORNER LH REAR
7 0E7809 1 POST CORNER RH REAR
8 0E8387 1 BAFFLE REAR TOP
9 0E6986 2 DOOR COMPARTMENT SIDE
10 0F5552 1 SUPPORT R/H SIDE
11 089961 2 FOAM STRIP 3/4" WIDE X 3/16" THK (40" LG)
12 0A2115 4 WASHER NYLON .257
13 0E8404 1 BRACKET STIFFENER LH FRONT
14 0D2538A 1 HINGE LIFT OFF TYPE B KNUCKLE
15 0D2538 1 HINGE LIFT OFF TYPE B PIN
16 078115 8 WASHER SELF LOCKING DOME
17 022097 12 WASHER LOCK M6-1/4
18 022473 12 WASHER FLAT 1/4-M6 ZINC
19 0E7570 2 GAS SPRING
20 0E7571 4 BALL STUD GAS SPRING MOUNT
21 070015 4 NUT HEX 5/16-18 LOCK
22 0E7662 4 SCREW WING M6-1.00 X 25
23 0D2537A 1 HINGE LIFT OFF TYPE A KNUCKLE
24 0D2537 1 HINGE LIFT OFF TYPE A PIN
25 0D2023 2 TRIM VINYL SELF GRIPPING (91" LG)
26 0E7869 2 BRACKET STIFFENING BACK
27 0E8001 1 MUFFLER BOX
28 0F5551 1 ROOF, W/SHOCK MOUNT
29 0E7966 1 BRACE FRONT TOP
30 0D3037A 1 LATCH 1/4 TURN NONLOCKING
31 0C7781 2 PAWL DOOR HSB
32 0E7794 1 SUPPORT LH SIDE
33 0E8052 1 MUFFLER BOX TOP
34 0D3037 1 LATCH QUARTER TURN LOCKING
35 0E8007 1 POST CORNER LH FRONT
36 0E8008 1 POST CORNER RH FRONT
37 0F4938 1 BRACE FRONT BOTTOM
38 0E8055 1 DUCT DISCHARGE MID FRONT
39 026850 4 WASHER SHAKEPROOF EXT 1/4 STL
40 0912970063 2 ASSY WIRE 14AWG 7.5 #0 GRN/YEL
41 0912970064 2 ASSY WIRE 14AWG 7.5 #0 GRN/YEL
42 049813 2 NUT HEX M6 X 1.0 G8 YEL CHR
43 0E8665 1 BRACKET STIFFENER LH FRONT
44 0D2023 1 TRIM VINYL SELF GRIPPING (165.5" LG)
45 0E7829N 2 AI ROOF PANEL 2
46 0E7829T 1 AI SUPPORT RH PANEL
47 0E7829S 1 AI SUPPORT LH PANEL
48 0E7829R 2 AI CORNER POST PANEL 2
49 0E7829P 4 AI CORNER POST PANEL 1
50 * 0E8442 1 KIT INSULATION 3.9L HSB
51 0E7829A 1 AI ROOF PANEL 1
52 0E7829B 2 AI DOOR PANEL
53 043116 8 SCREW HHC M6-1.0 X 12 G8.8
* ALL ITEMS NOTATED WITH "AI" ARE COMPONENTS OF 0E8442
Section 7 - Exploded Views and Parts
40kW Liquid-cooled Generators
Enclosure — Drawing No. 0F4931-C
