General Information
36949 B MMG25I-35D-45I-55DF4 Operating Manual 9
Unit Dimensions
Figure 2-1. Unit Dimensions
Specifications are subject to change without notice.
A (Width) B (Length) C (Height)
MMG25IF4/35DF4/45IF4/55DF4 -
Skid Mounted
39 in. (.99 m) 95 in. (2.41 m) 65 in. (1.65 m)
MMG25IF4/35DF4/45IF4/55DF4 -
Trailer Mounted
58 in. (1.45 m) 152 in. (3.81 m) 83 in. (2.11 m)
01906
C
C
BA
A B
