Owner’s Manual for Mobile Generator 5
General Information
Section 2 General Information
Component Locations
Figure 2-1. Component Locations
Table 2-1. Generator Components
A
Fuel Filler Location (under door)
E
Receptacle Panel (not available on MLG8 units)
B
Radiator Access Panel
F
Ground Studs (2)
C
Control Panel Locations (under door)
G
Safety Chains
D
Emergency Stop Switch (on MLG8 units,
switch is located on front panel)
H
Tongue Jack
