Generac Power Systems NP-50G Series

Generac NP-50G Recreational Vehicle Generator
FUEL REQUIREMENTS
The “NP” series generator is equipped with a gasoline fuel
system. Specific installations may provide either a separate
fuel tank for the generator, or the generator may “share” the
vehicle engine’s fuel tank.
NOTE: Some installations using a “shared” fuel tank may have
a generator fuel pickup tube that is shorter than the vehicle
engine’s pickup tube. Such an arrangement causes the gen¬
erator engine to “run out of gas” while adequate fuel for the
vehicle remains in the tank.
To reduce lead and carbon deposits use high quality
UNLEADED gasoline with the generator. Leaded REGULAR
grade gasoline is an acceptable substitute.
NOTE: Using “Unleaded" gasoline contributes to longer
engine valve life by reducing lead and carbon deposits.
CAUTION: Generac does not recommend using
any gasoline containing alcohol (such as “gaso-
hoi”). If you use any gasoline containing alcohol,
It must not contain more than 10 percent ethanol
and it must be removed from the generator during
storage. Do NOT use any gasoline containing
methanol. If you use gasoline with alcohol,
inspect more frequently for fuel leaks and other
abnormalities.
ENGINE OIL REQUIREMENTS
Use only high quality detergent oil rated with API service clas¬
sification SF, SG, or SH. The recommended oil weights include
the following:
• During summer months: SAE 30. An acceptable substitute
isSAE 10W-30.
• During winter months: SAE5W30. DO NOT USE SAE 10*
W40.
Crankcase and oil filter capacity is about 1400ml or about 1.5
U.S. quarts. Use no special additives. See “Maintenance" sec¬
tion for oil level check and fill procedures.
SPECIFICATIONS
■ ENGINE
Type of Engine.
Cooling Method.
Rated Horsepower.
Displacement.
Cylinder Block.
Type of Governor.
Air Cleaner.
Starter.;.
Ignition System.
Recommended Spark Plugs
Champion.
AC.
Ram Autollte.
Spark Plug Gap.
Recommended Minimum Battery
.GN-410, single-cylinder
.Air-cooled
.15 at 4200 RPM
.407cc
.Aluminum with cast iron sleeve
.Mechanical, fixed speed
Paper element with foam pre-cleaner
.12 volt DC electric
.Solid State with flywheel magneto
.RC12YC
.R45S
.65
.0.030 inch (0.76mm)
.400 CCA (cold cranking amps)
■ GENERATOR
Rotor RPM.3600
Rotor Poles.2
Engine RPM.2571
Rated Maximum Continuous
AC Output.4800 watts (4.8 kW)
Voltage . r.. 1 2 0 volts AC*
Rated Maximum Continuous AC Current.40 amperes**
Phase.single
Frequency.60 Hertz
Battery Charge Voltage.14 Volts DC
Battery Charge Current.2 amperes (max)
Weight.197 pounds (93 kg)
Length.25 inches (635mm)
Width.18.5 inches (470mm)
Height.15.75 inches(400mm)
* All units are reconnectable to 120 and/or 240 volts, dual voltage output.
Units are no longer listed per RVIA/ANSI when reconnected for dual volt¬
age output.
“ If reconnected for dual voltage, the ampere rating for 240 volts is 20 AC
amperes.
Recreational Vehicle Generator
13
