Owner’s Manual for Generac PWRcell Battery 5
General Information
Section 2: General Information
Specifications
Description Units PWRcell 9 PWRcell 12 PWRcell 15 PWRcell 17
Energy
Usable Energy kWh 8.6 11.4 14.3 17.1
Power
Continuous
*
kW 3.4 4.5 5.6 6.7
60 minutes
**
kW 4.2 5.6 7.0 8.4
2 minutes
**
kW 5.0 6.7 8.4 10.0
Battery Modules
Number - 3 4 5 6
DC Voltage (per module) VDC 46.8 (39-52)
REbus
Communication Protocol - REbus DC nanogrid
Voltage: Input/Output
***
VDC 360-420
Round-Trip Efficiency (DC to DC) % 96.5
Temperature
Operating Temperature Limits**** °F (°C) 41-113 (5-45)
Recommended Temperature Range °F (°C) 54-86 (13-30)
Installation Altitude
Maximum Installation Altitude
*****
ft (m) 9834 (3000)
Weight
Enclosure lb (kg) 115 (52)
Installed lb (kg) 280 (127) 335 (152) 390 (178) 445 (202)
Compliance
UL - UL 9540, UL 1973, UL 1642,
CSA - CSA 22.2
*Full cycle: 0% to 100% to 0% SoC @ 30° C
** Discharge @ 25° C
***380VDC Nominal
****Reduced performance at extreme temperatures
*****Module warranty void if installed above limit
Specifications are subject to change without notice. Refer to the product specification sheet for complete list.
