1 0F6717 1 ASSY RTR 390 30AD2 VERIZON
2 0F6716 1 ASSY STR 390 30AD2 VERIZON
3 068405 1 EXCITER FIELD 15" 2" LG
4 087272 1 ASSY EXCITER 2.00" STK
5 072878 1 KEY SQ 3/8 X 3-1/4 STEEL
6 0E6076 1 REVCOR FAN 12.63X2 W/PRESSDISK
7 0F5536 1 ASSY FLYWHEEL C2 CPL
8 023484K 1 BUSHING SNAP SB-1750-22
9 023454 1 KEY WOODRUFF #E
10 0F3398 8 SCREW SHC M10-1.5 X 16 G10.9
11 046526 8 WASHER LOCK M10
12 0A2601 1 SCREW HHC M16-2.0 X 45 G8.8
13 0A2602 1 WASHER FLAT .688ID X 3.25OD
14 0F6811 1 COVER, EXCITER
15 045771 4 NUT HEX M8-1.25 G8 CLEAR ZINC
16 022129 4 WASHER LOCK M8-5/16
17 092950 1 COLLAR SLIP FIT 390 MM
18 04576100CH 4 STUD M14-2.0 X 600 G5 ZINC
19 052646 4 WASHER FLAT M14
20 043123 4 WASHER LOCK M14
21 051779 4 NUT HEX M14-2.0 G8 YEL CHR
22 022392 2 PIN DOWEL 1/2 X 1-1/4
23 052259 2 WASHER FLAT M12
24 051769 3 WASHER LOCK M12
25 0E7230 2 SCREW HHC M12-1.75 X 80 G10.9
26 0C2428 2 SCREW PHTT #6-32 X 1/2 ZYC
27 022155 2 WASHER LOCK #6
28 077043F 1 CONDUIT FLEX 1.25” ID (18”LG)
29 020151 1 CLAMP VINYL .312 X .203 Z
30 023365 3 WASHER SHAKEPROOF INT #8
31 033133 1 SCREW HHM #8-32 X 3/8
32 033143 2 SCREW HHM #8-32 X 7/8
33 086032 2 LUG RT-ANG #10/10-12
34 090063 1 BRIDGE SUPPORT DIODE 15"
35 090064 1 CAP END ROTOR 390MM
36 090152 1 ASSY BRIDGE RECTIFIER
37 022661L 1 SLEEVING UL #0 .330 ID (3” LONG)
38 028739A 2 TIE WRAP UL 3.9" X .10" BLK
39 085662D 1 TIE WRAP UL 17.7 X .35 BLK HT
40 068113 1 CARRIER REAR BRG 15" (BRUSHLESS)
41 068406 3 SCREW HHC M12-1.75 X 60 G10.9
42 023484N 1 BUSHING SNAP SB-2.5-31
43 * 052624 1 BEARING BALL 6212 SEALED
44 0F4281B 2 XFMR CURRENT 150A W/BRKT
45 022145 4 WASHER FLAT 5/16-M8 ZINC
46 042907 4 SCREW HHC M8-1.25 X 16 G8.8
47 0F6812 1 COVER, EXCITER
48 0C2454 6 SCREW THF M6-1X16 N WA Z/JS
* ROTOR REPLACEMENT PARTS.
