COMPONENTS INCLUDED IN 01827E
1 0F1823 1 ENCL H CONTROL PANEL
2 0F1824 1 COVER CONTROL PANEL
3 0F2606 1 HINGE CONTINUOUS H-PANEL
4 036261 6 RIVET POP .125 X .275 SS
5 0F5763 1 ASSY PROGRAMMED PM H-100
6 0F1732 1 DECAL FUSES LOCATED INSIDE
7 0E9764 1 RAIL SNAPTRACK PCB HOLDER BULK (12”)
8 0F1740C 1 ASSY PCB 10A UL BATT CHRGR 12V
9 0F1958 1 PLATE HARNESS CLAMP
10 0F2256 1 ASSY PCB PWR AVR W/AMP HEADER
11 0E3161 1 ASSY PCB BOSCH GOV DRIVER
12 029673 1 DIO BRIDGE 25A 600V
13 049226 12 WASHER LOCK M5
14 079224 4 SCREW PPHM M5-0.8 X 30 SS
15 0D3876 12 WASHER FLAT M5
16 0F5886 7 SCREW HHPM M5-0.8 X 12
17 051716 5 NUT HEX M5-0.8 G8 CLEAR ZINC
18 0C3990 3 SCREW PHTT M4-0.7 X 10 ZYC
19 043180 3 WASHER FLAT M4
20 055014 10 SCREW PPHM M4-0.7 X 8 BLK OX
21 043184 10 WASHER LOCK M4
22 0F2557 1 DECAL WARNING BATT CHRG 12/24V
23 0F5884 1 SCREW PHTT M3.5-0.6 X 10
24 0F4333 1 CONN DUST CAP W/CHAIN DB9
25 0F5883 1 WASHER FLAT M3.5
26 0F6277 1 ASSY HARNESS H-PNL SW (NOT SHOWN)
COMPONENTS INCLUDED IN WIRE HARNESS
A 0F1263 1 ADAPTER RH SIDE WICKMAN 178.6191
B 0F1262 4 HOLDER FUSE WICKMANN 178.6150
C 0F1264 1 ADAPTER LH SIDE WICKMAN 178.6192
D 0E9049B 1 ASSY PCB G-PANEL RELAY 12VDC
E 055911 1 BLOCK TERM 20A 12 X 6 X 1100V
COMPONENTS INCLUDED IN 0F6979D
50 056739 1 RELAY SOLENOID 12VDC PNL MNT
51 048476 1 CB 4.5 X 1 AUT30KW CNT45K
52 0F5752B 1 RES WW 25R 5% 25W QK CONN
53 0F6145 AS REQ’D SEAL WEATHER .45"DIA
54 022287 2 SCREW HHC 1/4-20 X 3/4 G5
55 022473 4 WASHER FLAT 1/4-M6 ZINC
56 022097 2 WASHER LOCK M6-1/4
57 043182 3 WASHER LOCK M3
58 051714 3 NUT HEX M3-0.5 G8 YEL CHR
59 052777 3 WASHER FLAT M3
60 0C2323 2 SCREW PHTT #6-32 X 5/8 ZYC
61 0F5459 1 DECAL CPL CONTROL PANEL FUSES
62 0F5461 1 DECAL CPL 5.4/6.8L TB3
63 022127 2 NUT HEX 1/4-20 STEEL
64 0F5460 1 DECAL CPL 5.4/6.8L RELAY BOARD
65 0E7403C 1 FUSE ATO TYPE 15 AMP (BLUE)
66 0E7403B 2 FUSE ATO TYPE 10 AMP (RED)
67 0C2699 2 SCREW PHTT #6-32 X 3/8 ZYC
68 0F6305 2 SEAL COVER 3.18 X 12.7 X 382
69 0F6305A 1 SEAL COVER 3.18 X 12.7 X 283
70 0F5191 1 ASSY PCB FUEL PRES/FLUID BASN
71 091526 1 SCREW PPHM M5-0.8 X 12 ZNC
72 051713 1 WASHER FLAT M5
73 049226 1 WASHER LOCK M5
74 051716 1 NUT HEX M5-0.8 G8 CLEAR ZINC
75 081008B 2 GROMMET 1.25 X .25 X 1.00
76 0F7811 1 CORD POWER SUPPLY 3.9L VZW
To Next Page
