1 0F6643 1 REAR WRAP
2 0C2454 64 SCREW THF M6-1 X 16 N WA Z/JS
3 0F5849AG 2 DOOR C2 ALUM GRAY
4 ** 077992 5 NUT HEX LOCK M6-1.0 SS NY INS
5 0F3890A 6 RETAINER INSULATION (740)
6 0F6647 2 DISCHARGE DUCT L/H & R/H SIDE
7 0F6642 2 FRONT CORNERS
8 0F6650 1 DISCHARGE DUCT MIDDLE
9 049813 2 NUT HEX M6 X 1.0 G8 YEL CHR
10 022447 2 WASHER SHAKEPROOF INT 1/4
11 0F6644 1 ROOF
12 0E5968 1 GASKET EXTRUDED TRIM (158.50” LG)
13 0F5048D 2 VISE-ACTION LATCH SLOTTED CIR
14 022127 1 NUT HEX 1/4-20 STEEL
15 022097 1 WASHER LOCK M6-1/4
16 0F5049 2 TAB PULL
17 0C2634A 1 ASSEMBLY COVER ACCESS
18 022473 3 WASHER FLAT 1/4-M6 ZINC
19 042568 2 SCREW HHC M6-1.0 X 20 G8.8
20 0912970089 2 ASSY WIRE 14AWG 31.3" BLK
21 0F7306A 2 INSULATION SIDE SUPPORT
22 078115 12 WASHER SELF LOCKING DOME
23 0F7651 1 BAFFLE AIR
24 0F4051A 1 INSULATION ROOF TOP
25 089961 2 FOAM STRIP 3/4" WIDE X 3/16" THK (144” LG)
26 029289 4 TAPE ELEC 1/2 FOAM (40” LG)
27 029289 2 TAPE ELEC 1/2 FOAM (8” LG)
28 029289 1 TAPE ELEC 1/2 FOAM (33.187” LG)
29 0F7678 3 BRACKET AIR BAFFLE
30 0F9494 2 HEX KEY 5/16 (NOT SHOWN)
31 0F8869D 1 KEY VISE-ACTION LATCH SLOT CIR
** ALUMINUM ENCLOSURE NOTE: ALL ENCLOSURE PANELS THAT FASTEN TO
THE BASE FRAME MUST BE SECURED USING ITEM 2 & 5 THREAD FORMING
FASTENER AND ITEM 4 LOCK NUT. LOCK NUT IS TO BE INSTALLED AFTER THREAD
FORMING FASTENER HAS PENETRATED THROUGH EXTRUSIONS IN
ENCLOSURE PANELS.
