2.4M SERIES 1241 ANTENNA 4096-859

ASSEMBLY MANUAL REVISION A

Prodelin Corporation Page 11 8/17/2012

Parts List Continued

27 8202-041

Lock washer, 5/16” STD 24

28 8101-009

Nut, 5/16-18 Hex

0200-1829 Reflector Support Hardware Kit

29 8032-010

Bolt, 3/8-16 x 1.25 Hex

30 8201-042

Flat washer, 3/8” USS STD 28

31 8202-042

Lock washer 3/8” STD

32 8102-007

Nut, 3/8-16 Hex

33 8033-010

Bolt, 1/2-13 x 1.25 Hex

34 8201-043

Flat washer, 1/2 USS STD

35 8202-043

Lock washer, 1/2" STD
