General 15-010 M1

19
PARTS LIST
15-010
PART NO. DESCRIPTION SPECIFICATION QTY
15010-01 AUXILIARY TABLE 1
15010-02 END STEEL PLATE 1
15010-03 SELF-TAPPING SCREW 8
15010-05 TABLE MOUNTING BRACKET 1
15010-06 LOCK KNOB 1/2”-12NCX25X61 2
15010-07 WASHER 3/8”X20X2 24
15010-08 HEX HEAD BOLT 3/8”-16NCX2-1/2” 2
15010-09 ADJUSTMENT KNOB 2
15010-10 SPRING HOLDER 1
15010-11 HEX HEAD BOLT 1
15010-12 HEX NUT 3/8”-16NC 19
15010-13 SPRING 1
15010-14 PLATE COVER 2
15010-15 SOCKET HEAD BOLT 2
15010-16 IDLER ROLLER BRACKET 1
15010-17 SOCKET HEAD BOLT 4
15010-18 FRONT TABLE 1
15010-19 FRONT STEEL PLATE 1
15010-20 TABLE SUPPORT 2
15010-21 HEX HEAD BOLT 3/8”-16UNCX1” 9
15010-22 HEX HEAD BOLT 3/8”- 16UNCX5/8” 2
15010-23 HINGE HOLDER 1
15010-24 SPRING ADJUSTING BLOCK 2
15010-25 SPRING 1
15010-27 LOCK KNOB 5/16”-18NCX18X38 2
15010-28 C-RING 1
15010-29 BEARING 2
15010-30 TOP COVER 1
15010-31 IDLER ROLLER 1
15010-32 SANDING BELT 1
15010-33 TOP COVER SUPPORT 2
15010-34 PULLEY SHAFT 1
15010-35 STEEL PLATEN 1
15010-36 GRAPHITE COATING 1
15010-37 C-RING 1
15010-38 HINGE PIN 1
15010-39 FRONT TABLE MOUNTING BRACKET 1
15010-40 BASE 1
15010-41 TABLE HEIGHT ADJUSTING KNOB 1/2”-12NCX200X61 1
15010-42 HEX HEAD BOLT 1/4”-20UNC-3/8’ 8
15010-43 FLAT WASHER 8
15010-45 FLAT WASHER 4
15010-46 BACK PANEL 1
15010-47 LOCK KNOB (SMALL) 4
15010-48 RETAINING PLATE 2
15010-49 SOCKET HEAD BOLT 1
15010-50 DRIVE ROLLER 1
15010-51 HEX HEAD BOLT 1/2”-12UNCX6” 4
15010-52 HEX NUT 1/2”-12UNC 4
15010-53 SET SCREW 5/16” 1
15010-54 MOTOR 1
15010-56 KEY 7X7X70 1
15010-57 DUST HOOD 1
15010-58A MAGNETIC SWITCH 1
15010-59 FLAT WASHER 8
15010-61 ROUND HEAD BOLT M4 X0.7 2
