UNPACKING
BASIC FUNCTIONS
This 6" x 108" vertical edge belt sander has been designed for sanding or polishing (removing kerf or pencil marks)
on small workpieces, such as chair legs or cabinet doors. This sander is not intended (and should not be used) to
sand any material other than wood. The front table can be inclined left or right for sanding irregular workpieces
and the auxiliary/end table can be used for sanding round or curved surfaces. Both tables are height adjustable,
allowing you to use different sections of the belt depending on the height of the workpiece for an even wearing of
the sanding belt surface.
LIST OF CONTENTS QTY
SANDER..........................................................................1
FRONT TABLE
*
................................................................1
AUXILIARY TABLE
*
..........................................................1
DUST HOOD/END GUARD
*
..........................................1
TABLE HEIGHT ADJUSTIMENT KNOB..............................1
4 MM ALLEN KEY...........................................................1
5 MM ALLEN KEY...........................................................1
6 MM ALLEN KEY...........................................................1
12 -14 MM OPEN END WRENCH ..................................1
8 - 10 MM OPEN END WRENCH ...................................1
* The front table, auxiliary table and dust hood/end
guard are stored inside the sander cabinet to prevent
damage in shipping. Unscrew the 8 bolts using the 10
mm wrench supplied and remove the back panel.
Remove the components from the ca-binet and reinstall
the back panel, positioning it with the louvers facing
downward. (See picture below)
REAR VIEW
INSIDE VIEW
Carefully unpack and remove the sander and its components from the shipping crate and check for damaged or
missing items as per the list of contents below.
Note: Please report any damaged or missing items to your General International distributor immediately.
The plastic protective film on the front table must be
peeled off (see picture below).The plastic coating on the
auxiliary table is not to be r
emoved.
*
*
*
