General ASH12UMBD - REFRIGERANT SYSTEM DIAGRAM

REFRIGERANT SYSTEM DIAGRAM
52006.02.03
INDOOR UNIT A INDOOR UNIT B
EVAPOLATOR EVAPOLATOR
THERMISTOR ( PIPE TEMP. ) THERMISTOR ( PIPE TEMP. )
2-WAY VALVE
4-WAY VALVE
S C
4-WAY VALVE
S C E D
HEAT COOL
E D
2-WAY VALVE 3-WAY VALVE
CAPILLARY TUBE
U N I T B U N I T A
CAPILLARY TUBE
CAPILLARY TUBE CAPILLARY TUBE
3-WAY VALVE
MUFFLER
COMPRESSOR-A
THERMISTOR-A (DISCHARGE-PIPE)
THERMISTOR-A (CONDENSER) THERMISTOR-B (CONDENSER)
THERMISTOR (OUTDOOR TEMP.)
CONDENSER
COMPRESSOR-B
THERMISTOR-B (DISCHARGE-PIPE)
MUFFLER
STRAINER STRAINER
THERMISTOR ( ROOM TEMP. ) THERMISTOR ( ROOM TEMP. )
OUTDOOR UNIT
REFRIGERANT PIPE 9.52mm(3/8") REFRIGERANT PIPE 9.52mm(3/8") REFRIGERANT PIPE 6.35mm(1/4") REFRIGERANT PIPE 6.35mm(1/4")
