63 Front Panel Assy
9312172085
65 Flow Control Panel-Z
9306058043
69 Louver-A
9306055028
74 Filter
9305444014
108 Base
9309755062
109 Casing Assy
9312173037
122 Shaft Holder-B
9303066010
127 Drain Hose Assy
9305550029
146 Evaporator Assy
9373044017
151 Control Box
9330007017
158 Connecting Pipe Assy
9306416010
164 Fan Motor Assy-IN
9601844013
169 Cross-Flow Fan Assy
9307836015
184 Thermistor Spring
313728262708
196 Clamp SKB-150
313035356905
233 Power Transformer
9900028015
236 Controller PCB Assy
9705536050
(K03BK-0502HSE-C1)
281 Clamp Metal (Pipe) 9306063009
283 Bushing-A 9303529010
323 Louver-B 9306056025
385 Indicator PCB Assy 9705296015
401 Wall Hook Bracket 9304358008
440 Flow Control Panel-U 9306057046
522-1 Gear-A 9306062002
523 Gear Bracket 9306407001
652-1 Thermistor Holder Pipe 313714262805
759-1 Intake Grille-B 9330002012
764 Drain Cap Assy 9304150008
767-1 Bottom Cover 9330004016
777 Clamper (Grille) 9306755010
815 Terminal 9900040055
850 Window (Receiver) 9330003019
872 Indicator Case 9330009011
873 Lamp Cover 9330014015
874 Control Box Cover 9330008014
875 Power Supply PCB Assy 9705294011
876 Step Motor 9900139018
962-1 Guard Holder-L 9306678012
962-2 Guard Holder-R 9306677015
When you order parts, please make a photocopy of this page
and fill the number of the parts in the "Order" column.
INDOOR UNIT
Ref.
No.
Description
Ord.
Q'ty
Part No.
ASH12UMBD
240 Remote Control Unit
9314684029
PARTS LIST
222006.02.24
FOLS checked 2006/1/23
34 Capacitor (Fan Motor) 9900089061
