INDOOR UNIT
64 Capacitor (FanMotor) 9900284015
67 Rubber (Vibration-proof) 9361279001
468 Special Nut-A (Large) 313005446653
469 Special Nut-B (Small) 313005446759
470 Separate Wall-B 9359648000
474 Turbo Fan 9359658009
475 Cushion(Turbo Fan) 9366013006
GRILLE ASSY ( UTG-UDGD-W )
When you order parts, please make a photocopy of this page
and fill the number of the parts in the "Order" column.
Filter 9359632009
165 Motor Cover 9359623014
196 Clamp SKB-150 313035356905
226 Motor Gear 9359629009
385 Indicator PCB Assy 9702224011
392 Cover-A 9359622017
416 Insulation (Panel)-A 9359620006
417 Insulation (Panel)-B 9359621003
690 Joint-A 9359626008
691 Joint-B 9359627005
93 692 Joint Shaft 9359625001
694 Cam Gear 9359628002
700 Panel 9359619017
705 Louver 9374951017
710 Intake Grille 9370126006
711-1 Filter Clamp-A 9359634003
711-2 Filter Clamp-B 9359635000
758 Decoration Plate-A 9360039026
763 Receiver Cover 9359630005
776 Grille Stopper 9359633013
777 Grille Hook 9359761006
876-2 Step Motor 9900362027
Ref.
No.
Description
Ord.
Q'ty
Part No.
Ref.
No.
Description
Ord.
Q'ty
Part No.
Ref.
No.
Description
Ord.
Q'ty
Part No. Part No.
Ref.
No.
Description
Ord.
Q'ty
AUH12UMAB AUH12UMAB
476-3 Special Washer 9359954002
478 Sensor M. Bracket 9359654001
484 Hanger Metal 9359644002
488 Drain Pan Plug 9359653004
495 Clamp No. 2U46 9352715006
514 Control Box Cover 9359662006
628 Locking Spacer-B 313005446558
652-1 Thermistor Holder Pipe 313806262805
743 Remocon Holder 9305642014
797 Separate Wall-C 9359649007
798 Pump Hook Bracket 9359650003
815 Terminal-3P 9900203016
824-3 Fuse 0600222512
834 Wire Cover 9359878001
835 Cushion-A (For Pump) 9352211003
836 Cushion-B (For Pump) 9356084016
875 Filter PCB Assy 9704561046
965 Flare Nut-B 9351062019
989-1 Cord Clamp-A 9359822011
989-2 Cord Clamp-B 9359823018
990 Distributor Assy 9373034049
465 Body-B 9359645009
467 Drain Port 313005415658
127 Drain Hose 9359659013
138 Special Wall-A 9359647003
146 Evaporator Assy 9373214014
160 Drain Pan 9359651000
164 Fan Motor Assy-In 9601040019
184-1 Thermo. Spring-A 313728262708
185 Rubber Bushing 313005066051
187 Clamp No. 1219 313361271706
223 Control Box 9359661016
196 Clamp SKB-150 313035356905
234 Thermistor Assy-Room 9703299032
235 Thermistor Assy-Pipe 9703297014
236 Control PCB Assy
(EZ-0032EHSE-C)
9704557605
240 Remocon Assy 9371190037
244 Pipe Cover 9359646006
287 Cap (Power) 9352173011
301 Clamp NK-2N 313985355201
313 Hooking Wire 9359983002
338 Motor Fixture 9359656005
381 Locking Spacer 313209391506
395 Eva Holder 9373179016
399 Air Duct 9359660002
411 Supporter-A 9359655008
430 Clamp NK-7N 313095365602
457 Drain Pan Support 9359652007
464 Body-A 9359643005
462 Top Cover Plate 9359642015
232006.01.24
FOLS checked 2006/1/23
To Next Page
