When you order parts, please make a photocopy of this page
and fill the number of the parts in the "Order" column.
OUTDOOR UNIT
Ref.
No.
Description
Ord.
Q'ty
Part No.
AOY24USBV2
242006.03.16
1 Top Panel Sub Assy 9374417018
2 Front Panel S 9374094080
3 Fan Guard 9374330010
4 Grip Side 9374173013
5 Service Panel Sub Assy 9374415045
6 Right Panel 9374599042
9 Grip 9374172016
10 Print Net S 9374255047
11 Propeller Fan Assy 9366378013
12 Motor, Induction 9601671060
13 Condenser A Assy 9374433094
14 Separate Wall S 9374135042
15 Base Assy 9374166121
18 Cap Foot 9374345014
19 Motor Bracket Sub Assy 9374418084
61 OCR Assy 9312899005
62 Special Nut 9355091008
63 Rubber Seat (Comp)A 9351813017
--- Emblem Rear 9372171011
23 Compressor Cover A 9375323011
24 Compressor Cover B 9374431076
25 Compressor Cover C 9372067055
27 Compressor Plate Assy 9375221027
28 Compressor Assy 9373010036
29 4-Way Valve A Assy 9375293017
30 4-Way Valve B Assy 9375294014
41 Joint Pipe (Valve) A Assy 9375295011
42 Joint Pipe (Valve) B Assy 9375296018
46 PCB Assy 9707096019
47 Band (Capacitor) 9352123009
48 Capacitor, Plastic (Comp.) 9900269036
49 Capacitor, Plastic (Fan) 9900270049
50 Relay 9900264017
51 Terminal 9900203047
52 Clamp (Cord) C 9359677000
53 Clamp (Cord) 9356857009
54 Clamp No.1219 313361271706
55 Wire Clamper 0600231019
56 Clip (Cable) No 1259 313739340109
57 Thermistor Assy 9900356019
58 Special Nut M5 313199233602
59 Terminal Cover (Comp) 9351120009
60 Terminal Gasket (Comp) 9351121006
35 Inlet Pipe (Cond) A1 Assy 9373461081
36 Inlet Pipe (Cond) B1 Assy 9373463061
37 Outlet Pipe (Cond) A Assy 9374266098
38 Outlet Pipe (Cond) B Assy 9375292010
39 Capillary A Assy 9375297015
40 Capillary B Assy 9375298012
FOLS checked 2006/1/23
31 3-Way Valve Assy 9375103019
32 2-Way Valve Assy 9375102012
33 Solenoid (A=White) 9900165079
34 Solenoid (B=Red) 9900165062
To Next Page
