CAPACITY AND SPECIFICATIONS:
Accommodates stock from 1/2 in. to 1 in. thick.
WHAT’S IN THE JIG KIT
The fully assembled jig
Two router table guide knobs
One 14° x 1/2 in. dovetail router bit with guide bearings
(1/4 in. shank)
One alignment tool
One allen wrench
It is highly recommended that you familiarize yourself with the nomenclature in Fig. 3 before
proceeding.
4
FIG. 3
861 Dovetailer II Manual 11P-081711_Layout 1 8/17/11 5:12 PM Page 4
