General DOVETAILER II

1
0. Make all cuts to the pins board. For those cuts, the router should ride on the surface
marked “cut pins this side” shown in FIG. 13 & 14. Be sure to follow the jig profile.
11. Dry fit the two sections together. If problems arise, file or trim the joint as needed.
9
FIG. 13
FIG. 14
